Features
Category 1 and 2 Implement Compatibility
The 4M Heavy-Duty Tractor’s 3-point hitch system offers high implement versatility with Category 1 and 2 compatibility, telescoping draft links, and a lift capacity of up to 3130 lb (1420 kg) at the lift link ends. Its position control lever, rate-of-drop valve, and adjustable stabilizers ensure precise, consistent implement depth and easy attachment without tools.
Maximize Productivity With an eHydro™ Transmission
The eHydro™ transmission offers seamless operation with an infinitely variable ground speed, no clutching for direction changes, and integrated Twin Touch™ foot controls for quick and easy forward/reverse movement. It maximizes tractor productivity, reduces powertrain shock loads, and enhances operator comfort by providing high torque for startup.
Excellent Visibility Provided by Standard Lighting Equipment
Standard lighting equipment includes wide-angle halogen headlights with premium automotive-style bezels, amber flashing warning lights, and fender-mounted working lights, all compliant with ASAE S279 standards.
Engine
| Engine Model | 4TNV86CT-MJT |
| Engine Family | EYDXL2.09TDA, FYDXL2.09TDA, GYDXL2.09TDA |
| Emissions Certifications | Final Tier 4 |
| Displacement | 127 cu in. |
| Aspiration | Turbocharged |
| Number of Cylinders | 4 |
| Cylinder Liners | Cast-in-block |
| Rated Engine Speed | 2600 rpm |
| Rated Engine Power | 51 hp |
| Rated Engine Power | 38 kW |
| Rated Engine Power | 51 PS |
| Compression Ratio | 19.1:1 |
| Lubrication | Pressurized |
| Cooling System Type | Liquid |
| Fuel Type | Diesel; High-pressure common rail direct injection |
| Air Cleaner Type | Dual element with electronic restriction indicator |
Front Axle
| Front Axle Differential Lock | Yes |
Hydraulics
| Hydraulic System Type | Open center |
| Auxiliary Hydraulic Features | Standard: Two remote control valves |
Rear Axle
Machine Configuration
| Wheel or Track Configuration | Wheel |
Tires
| Front Tires Size | R4 Industrial 31.5x13-16.5 |
Steering & Brakes
| Primary Brakes | Multi-plate wet disc |
Rear Hitch
| Draft Control Sensing | Position control |
Rear Power Take-Off (PTO)
| Economy PTO Speeds | 540 rpm |
| Engagement Method | Independent |
| PTO Clutch | Wet disc |
Electrical System
| Alternator Capacity | 75 amp |
Transmission
| Creeper | SpeedMatch™ standard |
| Clutch | Wet |
| Cruise Control | Standard |
