Features
Easy-to-Use eHydro™ Transmission
The eHydro™ transmission provides seamless, gradual speed shifts, requiring no clutching. Its Twin Touch™ foot controls allow for quick, precise direction and speed changes, ideal for loader or mower applications, enhancing overall productivity.
More Time Working, Less Time Switching Implements
John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.
Comfortable, Easy Operation
Step in and get to work with a 3R Tractor designed to keep you comfortable and in control. A spacious, easy-to-navigate operator station gives you plenty of room, intuitive controls, and smooth entry and exit for long days on the job. For added comfort in any season, an optional ComfortGard™ cab surrounds you with a quiet, climate-controlled environment with excellent visibility.
Engine
| Engine Model | 3TNV86CHT-MJTV |
| Emissions Certifications | Final Tier 4 |
| Displacement | 96 cu in. |
| Aspiration | Turbocharged and intercooled |
| Number of Cylinders | 3 |
| Cylinder Liners | Cast-in-block |
| Rated Engine Speed | 2600 rpm |
| Rated Engine Power | 45 hp |
| Rated Engine Power | 33 kW |
| Rated Engine Power | 45 PS |
| Compression Ratio | 19.1:1 |
| Lubrication | Pressurized |
| Cooling System Type | Liquid |
| Fuel Type | Diesel |
| Air Cleaner Type | Dual element |
Hydraulics
| Hydraulic System Type | Open center |
| Number of Rear Selective Control Valves (SCVs) | Up to 6 |
Rear Power Take-Off (PTO)
| PTO Category | Independent rear: 540 rpm |
| Optional PTO Category | Mid: 2100 rpm |
| Engagement Method | Lever and switch |
| PTO Clutch | Wet disk |
| Brake (For Mid and Rear PTO) | Wet disk |
Rear Axle
Machine Configuration
| Wheel or Track Configuration | Wheel |
| Drive Type | 4WD |
Tires
| Front Tires Size | R1 Bar: 7-14; R3 Turf: 27x8.50-15; R3 Turf Special: 25/10.5LLx15; R4 Industrial: 25x8.5-14 or 27x8.5-15 |
Steering & Brakes
Rear Hitch
| Draft Control Sensing | Position control |
Electrical System
| Alternator Capacity | 75 amp |
Transmission
