Features
Comfortable Operator Station
Operators will appreciate the uncluttered design of the operator station, promoting comfort with color-coded controls and a contoured seat that adjusts for an optimal fit. The flat platform ensures easy entry and exit.
Easy-to-Use Hydrostatic Transmission
The 3E Tractors feature a hydrostatic transmission (HST) for superior performance. It provides infinite ground speeds that let operators easily match their speed to the task at hand. The Twin Touch™ foot pedals make forward and reverse motion effortless, enhancing operator comfort and control.
More Time Working, Less Time Switching Implements
John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.
Engine
| Engine Model | 3TNV86CT-NJT2 |
| Engine Family | FYDXL1.57TDA, EYDXL1.57TDA, GYDXL1.57TDA |
| Emissions Certifications | Final Tier 4 |
| Displacement | 96 cu in. |
| Aspiration | Turbocharged |
| Number of Cylinders | 3 |
| Cylinder Liners | Cast-in-block |
| Rated Engine Speed | 2500 rpm |
| Rated Engine Power | 37 hp |
| Rated Engine Power | 27 kW |
| Rated Engine Power | 37 PS |
| Compression Ratio | 19.1:1 |
| Lubrication | Pressurized |
| Cooling System Type | Water pump |
| Fuel Type | Diesel |
| Air Cleaner Type | Dual element |
Hydraulics
| Hydraulic System Type | Open center |
| Number of Rear Selective Control Valves (SCVs) | 2 |
Rear Power Take-Off (PTO)
| PTO Category | 540 rpm |
| Engine rpm at Rated PTO Speeds (540/1.000) | 2500 |
| Engagement Method | Independent |
| PTO Clutch | Wet disk |
| Brake (For Mid and Rear PTO) | Wet disk |
Rear Axle
Machine Configuration
| Wheel or Track Configuration | Wheel |
| Drive Type | 4WD |
Tires
| Front Tires Size | R1 Bar: 7-14; R3 Turf: 27x8.5-15; R4 Industrial: 25x8.5-14 / 27x8.5-15 |
Steering & Brakes
Rear Hitch
| Draft Control Sensing | Position control |
Electrical System
| Alternator Capacity | 55 amp |
Operator Station
| Gearshift Location | Left-hand side |
Transmission
| Creeper | No |
| Cruise Control | Optional |
