Features
Clean and Simple Operator Station
The 3D operator station is designed to keep operation comfortable, simple, and intuitive throughout the workday. An easy step‑through layout and thoughtfully placed controls support confident operation and reduce unnecessary effort when getting on and off. The clean, practical design helps you stay focused on the task at hand without added complexity.
Optional iMatch™ Quick-Hitch Feature
John Deere’s iMatch™ Quick-Hitch simplifies implement attachment by ensuring a guaranteed fit for all ASABE Category 1-compatible tools, using included bushings to align implement pins with hitch hooks.
Optional Two-Spool Rear Selective Control Valve (SCV)
3D Series Tractors can be upgraded with a rear hydraulic remote kit that adds two independent hydraulic spools, enabling compatibility with various rear attachments like angled blades and snow blowers. The first spool includes a float position for better landscape contouring and grading precision.
Engine
| Engine Model | 3TNV88F-EPJPT |
| Emissions Certifications | Final Tier 4 |
| Displacement | 100 cu in. |
| Aspiration | Natural |
| Number of Cylinders | 3 |
| Cylinder Liners | Cast-in-block |
| Rated Engine Speed | 2400 rpm |
| Rated Engine Power | 24 hp |
| Rated Engine Power | 18 kW |
| Rated Engine Power | 25 PS |
| Compression Ratio | 19.1:1 |
| Lubrication | Pressurized |
| Cooling System Type | Liquid |
| Fuel Type | Diesel |
| Air Cleaner Type | Dual element |
Hydraulics
| Hydraulic System Type | Open center |
| Number of Rear Selective Control Valves (SCVs) | 2 |
Rear Power Take-Off (PTO)
| PTO Category | 540 rpm |
| Engine rpm at Rated PTO Speeds (540/1.000) | 2400 |
| Engagement Method | Mechanical |
| PTO Clutch | Transmission |
| Brake (For Mid and Rear PTO) | Wet disk |
Rear Axle
Machine Configuration
| Wheel or Track Configuration | Wheel |
| Drive Type | 4WD |
Tires
| Front Tires Size | R1 Bar: 7-14 R3; Turf: 27x8.5-15 R4; Industrial: 25x8.5-14 |
Steering & Brakes
Rear Hitch
| Draft Control Sensing | Position control |
Electrical System
| Alternator Capacity | 55 amp |
Operator Station
| Gearshift Location | Right-hand side |
Transmission
| Creeper | No |
| Cruise Control | No |
