Features
Hydrostatic Transmission
Equipped with a standard HST transmission featuring Twin Touch™ foot pedals, this compact utility tractor offers increased performance and convenience. The hydrostatic drive allows for infinite ground speeds even at full throttle, providing smooth and precise operation, particularly useful for loader and mower applications.
Open Operator's Station
The design of the operator's station focuses on comfort and visibility with a sloped hood, high-back seat, and easy step-through access. The controls are color-coded for ease of use, enhancing the overall operator experience and making control and visibility clear during operation.
More Time Working, Less Time Switching Implements
John Deere Compact Tractors are built for fast, tool-free implement changes, enabling users to switch tasks efficiently. With Quick Connect Solutions like the AutoConnect™ Deck System, Quik-Park™ Loader, iMatch™ Quick Hitch, and Quik-Knect™ PTO connector, operators can attach or detach implements in under a minute—often without leaving the seat.
Engine
| Engine Model | 3TNV80F-NCJT |
| Emissions Certifications | Final Tier 4 |
| Displacement | 77 cu in. |
| Aspiration | Natural |
| Number of Cylinders | 3 |
| Cylinder Liners | Cast-in-block |
| Rated Engine Speed | 3200 rpm |
| Rated Engine Power | 24 hp |
| Rated Engine Power | 18 kW |
| Rated Engine Power | 24 PS |
| Compression Ratio | 23.1:01 |
| Lubrication | Pressurized |
| Cooling System Type | Water pump |
| Fuel Type | Diesel |
| Air Cleaner Type | Dual element |
Hydraulics
| Hydraulic System Type | Open center |
| Number of Rear Selective Control Valves (SCVs) | 2 |
Rear Power Take-Off (PTO)
| Economy PTO Speeds | Rear: 540 rpm; Mid: 2100 rpm |
| Engagement Method | Independent |
| PTO Clutch | Wet disk |
| Brake (For Mid and Rear PTO) | Wet disk |
Rear Axle
Machine Configuration
| Wheel or Track Configuration | Wheel |
Tires
| Front Tires Size | R3 Turf: 23x8.50-12; R3 Radial: 220/55-R12; R4 Industrial: 23x8.50-12 |
Steering & Brakes
Rear Hitch
| Draft Control Sensing | Position control |
Electrical System
| Alternator Capacity | 40 amp |
Drawbar
| Drawbar Category | Position control |
Operator Station
| Gearshift Location | Left-hand side |
Transmission
| Creeper | No |
| Cruise Control | Standard |
