Features
Compatible with the iMatch™ Quick-Attach Hitch System
All Frontier™ Wood Chipper models are compatible with the iMatch™ ASAE Category 1 quick-attach hitch system. iMatch converts your tractor’s 3-point hitch to fixed hooks and attaching points for quick and easy connection. (iMatch hitch sold separately.)
Tackle Big Jobs Faster
The hydraulic feed roll handles a variety of wood sizes. Adjustable spring tension lets you choose the setting needed in your operation, so you can tackle big jobs faster.
Adjustable Discharge Chute
This chipper includes a 360-degree rotating discharge chute that provides fast and easy positioning. The adjustable deflector accurately directs wood chips to the desired location, enhancing user convenience and operational efficiency.
Weights
| Unit | 352 kg |
| Unit | 775 lb. |
| Rotor Style | Disc |
| Rotor Weights | 165 lb. |
| Rotor Weights | 75 kg |
Chip Chute
| Adjustable Chip Chute | Rotation: 360 degree (angle) |
Feed Options
| Feed Options - System | Hydraulic |
| Feed Options - Hopper Height | 21 in. |
| Feed Options - Hopper Height | 53 cm |
Tractor Compatibility
| HP Range (Tractor PTO hp) | 35-95 hp |
| HP Range (Tractor PTO hp) | 26-70.8 kW |
| PTO rpm | 540 rpm |
Dimensions
| Chip Opening | 140x203 mm |
| Chip Opening | 5.5x8 in. |
| Hopper Opening | 28x28 in. |
| Hopper Opening | 711x711 mm |
Chipping
| Knife Size | 2.5x3.25x0.3125 in. |
| Knife Size | 63.5x82.6x7.9 mm |
| Shear Bar | Adjustable hardened anvil |
| Chipping Rotor rpm | 1380 rpm |
| Knife Quantity | Four |
| Knife Bolt | Hardened and recessed bolts: 9.5 mm 0.375 in. |
Belt Drive System
| Belt Drive System - Number | Three |
3-Point Hitch
| 3-Point Hitch Category | Category 1, Category 2 |
Hydraulics
| Hydraulics Requirements | 22.7 L/min 6 gpm |
| Self-Contained Hydraulics System | Optional |
Warranty
| Warranty Time Period | 1 year |
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
