Features
Compatible with the iMatch™ Quick-Attach Hitch System
All Frontier™ Wood Chipper models are compatible with the iMatch™ ASAE Category 1 quick-attach hitch system. iMatch converts your tractor’s 3-point hitch to fixed hooks and attaching points for quick and easy connection. (iMatch hitch sold separately.)
Drive System Operates Efficiently
The belt drive system allows the WC11 Series Wood Chippers to operate using less horsepower while keeping the rotor rpm at a range from 1380 to 1920 rpm, depending on the model. The WC1103 is a single belt drive, while the WC1105 has three belts.
Adjustable Discharge Chute
This chipper includes a 360-degree rotating discharge chute that provides fast and easy positioning. The adjustable deflector accurately directs wood chips to the desired location, enhancing user convenience and operational efficiency.
Weights
| Unit | 295 kg |
| Unit | 650 lb. |
| Rotor Style | Disc |
| Rotor Weights | 165 lb. |
| Rotor Weights | 75 kg |
Chip Chute
| Adjustable Chip Chute | Rotation: 360 degree (angle) |
Feed Options
| Feed Options - System | Manual (gravity) |
| Feed Options - Hopper Height | 41 in. |
| Feed Options - Hopper Height | 104 cm |
Tractor Compatibility
| HP Range (Tractor PTO hp) | 25-85 hp |
| HP Range (Tractor PTO hp) | 18.6-63.4 kW |
| PTO rpm | 540 rpm |
Dimensions
| Chip Opening | 140x203 mm |
| Chip Opening | 5.5x8 in. |
| Hopper Opening | 28x28 in. |
| Hopper Opening | 711x711 mm |
Chipping
| Knife Size | 2.5x3.5x0.3125 in. |
| Knife Size | 63.5x89x7.9 mm |
| Shear Bar | Adjustable hardened anvil |
| Chipping Rotor rpm | 1380 rpm |
| Knife Quantity | Four |
| Knife Bolt | Hardened and recessed bolts: 9.5 mm, 0.375 in. |
Belt Drive System
| Belt Drive System - Number | Three |
3-Point Hitch
| 3-Point Hitch Category | Category 1, Category 2 |
Warranty
| Warranty Time Period | 1 year |
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
