Features
Compatible with the iMatch™ Quick-Attach Hitch System
All Frontier™ Wood Chipper models are compatible with the iMatch™ ASAE Category 1 quick-attach hitch system. iMatch converts your tractor’s 3-point hitch to fixed hooks and attaching points for quick and easy connection. (iMatch hitch sold separately.)
Drive System Operates Efficiently
The belt drive system allows the WC11 Series Wood Chippers to operate using less horsepower while keeping the rotor rpm at a range from 1380 to 1920 rpm, depending on the model. The WC1103 is a single belt drive, while the WC1105 has three belts.
Two Position Fixed Chip Chute
Feed chute direction changes can be made simply by removing the bolts and repositioning the chute to the opposite direction. (Tools required)
Weights
| Unit | 170 kg |
| Unit | 375 lb. |
| Rotor Style | Disc |
| Rotor Weights | 65 lb. |
| Rotor Weights | 29.5 kg |
Feed Options
| Feed Options - System | Manual (gravity) |
| Feed Options - Hopper Height | 38 in. |
| Feed Options - Hopper Height | 96 cm |
Tractor Compatibility
| HP Range (Tractor PTO hp) | 18-40 hp |
| HP Range (Tractor PTO hp) | 13.4-29.8 kW |
| PTO rpm | 540 rpm |
Dimensions
| Chip Opening | 76x140 mm |
| Chip Opening | 3x5.5 in. |
| Hopper Opening | 25x18 in. |
| Hopper Opening | 635x457 mm |
Chipping
| Knife Size | 2.5x3.5x0.3125 in. |
| Knife Size | 635x89x7.9 mm |
| Shear Bar | Adjustable hardened anvil |
| Chipping Rotor rpm | 1920 rpm |
| Knife Quantity | Two |
Belt Drive System
| Belt Drive System - Number | One |
3-Point Hitch
| 3-Point Hitch Category | Category 1 |
Warranty
| Warranty Time Period | 1 year |
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
Chip Chute
| Fixed Chip Chute | 2 positions |
