Features
SS20 Series Hitching Capabilities
The broadcast spreader is compatible with tractors featuring Category 0 and Category 1 3-point hitches.
Hopper-Enhanced Technology Ensures Long Wear Life
The spreader's hopper is crafted from polyethylene, which resists moisture and chemicals. This ensures a longer wear life, even in harsh conditions. A seamless conical design promotes quick, easy flow, aided by a standard fixed agitator.
SS20 Series Power Take-off (PTO) Driven Broadcast Spreaders
The spreader features a 540-rpm PTO. It comes with a sealed, heavy-duty gearbox containing extreme pressure (EP) grade grease, ensuring robust and reliable performance.
Dimensions
| Hopper Loading Height | 86.4 cm |
| Hopper Loading Height | 34 in. |
| Hopper Width | 35 in. |
| Hopper Width | 88.9 cm |
Weight
| Shipping (Per Pair) | 290 lb. |
| Shipping (Per Pair) | 131.5 kg |
| Hopper Capacity | 164.2 kg |
| Hopper Capacity | 362 lb. |
| Machine | 46.3 kg |
| Machine | 102 lb. |
Range
| Swath Spread | 7 m |
| Swath Spread | 23 ft |
PTO
| Tractor Horsepower Range | 16-45 hp |
| Tractor Horsepower Range | 12-33.5 kW |
| Shaft Category | 1: Heavy-duty shielded; 3.5 cm 1.375 in. |
| RPM | 540 rpm |
Hopper
| Volume Capacity | 5.6 cu ft |
| Volume Capacity | 0.16 m³ |
| Material | Polyethylene |
