Features
Precision Spreading Spout
Designed for precise distribution, the Frontier™ pendular spreaders come with various spreader spouts made of nylon and reinforced fiberglass, enhancing their resistance to corrosion and durability. The optional directional spout allows easy spread adjustment to the left, right, or center by simple rotation.
Corrosion-Resistant Hopper
The reinforced fiberglass hopper on the 11 Series Pendular Spreader guarantees superior corrosion resistance, resulting in stronger durability and longer wear life. The frame is made of sturdy, tubular steel and the hopper is painted with polyester resin powder coat for added corrosion resistance.
Drive System Provides Precision and Strength
The spreader's drive system includes a 540-rpm PTO and a heavy-duty, shielded shaft. Built in compliance with ASABE standards, it features a cast-steel gearbox that operates in an oil bath, which enhances longevity and performance while ensuring safety.
Dimensions
| Hopper Loading Height | 109.2 cm |
| Hopper Loading Height | 43 in. |
Weight
| Shipping (Per Pair) | 420 lb. |
| Shipping (Per Pair) | 191 kg |
| Hopper Capacity | 820.1 kg |
| Hopper Capacity | 1808 lb. |
| Machine | 153.8 kg |
| Machine | 339 lb. |
Range
| Swath Spread | 5.2-14.3 m |
| Swath Spread | 17-47 ft |
PTO
| Tractor Horsepower Range | 20-60 hp |
| Tractor Horsepower Range | 14.9-44.7 kW |
| RPM | 540 rpm |
Hopper
| Volume Capacity | 34.7 cu ft |
| Volume Capacity | 0.98 m³ |
| Material | Reinforced fiberglass |
Warranty
Setup Time
Hitch
| Type | 3-point, Category 1, Category 2 |
