Features
Category 1 Power Take-off (PTO) Driveline
The 10 Series Pendular Spreader comes standard with a 540-rpm PTO, Category 1 driveline. Its heavy-duty shielded shaft, made in compliance with American Society of Agricultural and Biological Engineers (ASABE) requirements, is built to last and ensures operator safety. The anti-wear, cast-steel gearbox operates in an oil bath, providing a longer life and durability for the driveline.
Reinforced Fiberglass Hopper
The reinforced fiberglass hopper guarantees superior corrosion resistance, resulting in increased durability and longer wear life. It comes complete with a frame made of sturdy, tubular steel and painted with polyester resin powder coat for added corrosion resistance.
Precision Spreading Spout
Designed for precise distribution, the Frontier™ pendular spreaders come with various spreader spouts made of nylon and reinforced fiberglass, enhancing their resistance to corrosion and durability. The optional directional spout allows easy spread adjustment to the left, right, or center by simple rotation.
Dimensions
| Hopper Loading Height | 109.2 cm |
| Hopper Loading Height | 43 in. |
Weight
| Shipping (Per Pair) | 590 lb. |
| Shipping (Per Pair) | 267.6 kg |
| Hopper Capacity | 261.3, 371.9 kg |
| Hopper Capacity | 576, 820 lb. |
| Machine | 117.9 kg |
| Machine | 260 lb. |
Range
| Swath Spread | 5.2-14.3 m |
| Swath Spread | 17-47 ft |
PTO
| Tractor Horsepower Range | 20-60 hp |
| Tractor Horsepower Range | 14.9-44.7 kW |
| RPM | 540 rpm |
Hopper
| Volume Capacity | 9, 12.8 cu ft |
| Volume Capacity | 0.25, 0.36 m³ |
| Material | Polyethylene |
Warranty
Hitch
| iMatch™ Compatible | Yes |
| Type | 3-point, Category 1 |
Setup Time
