Features
iMatch™ Quick-Hitch Compatibility
The iMatch™ quick-hitch system converts the tractor's 3-point hitch to fixed hooks for a super-quick connection.
Compression Springs Provide Added Force
The SP22 Series features two 160-lb. (72.6-kg) compression springs to ensure the roller remains in contact with the ground. This force allows the spikes to penetrate the soil up to 1-in. (25.4-mm) deep, providing effective soil pulverization.
Cutting Teeth for Superior Soil Preparation
The SP20 Series Soil Pulverizers feature a double set of 0.5-in. x 2-in. (12.7-mm x 50.8-mm) bar-type cutting teeth. Their staggered mounting slices the surface every 2.8-in. (71.1-mm) for superior soil preparation. The teeth are reversible for extra life.
Scarifying Teeth
| Scarifying Teeth - Rear Quantity | 14 |
| Scarifying Teeth - Front Quantity | 15 |
| Rear Dimensions | 1.3x5.1 cm |
| Rear Dimensions | 0.5x2 in. |
| Front Dimensions | 0.5x2 in. |
| Front Dimensions | 1.3x5.1 cm |
| Type Of Scarifying Teeth | Bar |
Dimensions
| Height | 39 in. |
| Height | 99.1 cm |
| Working Width | 213.4 cm |
| Working Width | 84 in. |
| H-Beam | 30.5x29.2 cm |
| H-Beam | 12x11.5 in. |
Weight
| Operating Weight | 396.9 kg |
| Operating Weight | 875 lb. |
| Shipping Weight | 940 lb. |
| Shipping Weight | 426.4 kg |
Tractor Compatibility
| Tractor Horsepower | 22.4-52.2 kW |
| Tractor Horsepower | 30-70 hp |
Compression Springs
| Down Pressure Per Spring | 160 lb. |
| Down Pressure Per Spring | 72.6 kg |
| Quantity | 2 |
Roller
| Roller Pin Quantity | 124 |
| Bearing Size | 2.5 cm |
| Bearing Size | 1 in. |
| Roller Pin Size | 0.38x1 in. |
| Roller Pin Size | 1x2.5 cm |
| Roller Diameter | 6.6 in. |
| Roller Diameter | 16.8 cm |
Second Roller Assembly (Optional)
| Spring Down Pressure Per Spring | 36.3 kg |
| Spring Down Pressure Per Spring | 80 lb. |
| Spring Quantity | 2 |
