Features
Adjustable Skid Shoes Increase Durability
The adjustable steel skid shoes on the SB13 Series increase the durability and life of the snowblowers.
Hydraulic Drum Rotation
On all SB13R models, the hydraulic drum rotation is standard and is great for operators who want to move large amounts of snow at a faster rate of speed while consuming less horsepower when discharging snow out the drum door. The drum door is hydraulically opened and closed, allowing operators to discharge snow to the side when it is open or discharge snow through the chute when the door is closed. All of this can be done without ever leaving the seat of the tractor.
Hydraulic Chute Rotation Blows Snow Anywhere
All SB13 Series Snowblowers are equipped with hydraulic chute rotation. Chute rotation adds versatility by allowing the operator to blow snow exactly where they want it to go.
Warranty period
| Gear Box Warranty Period | 1 year |
| Machine Warranty Period | 1 year |
Auger
| Auger Diameter | 55.9 cm |
| Auger Diameter | 22 in. |
| Auger Speed | 170 rpm |
| Auger Overload Protection | Single, dual is optional |
Weights
| Operating Weight | 1670 lb. |
| Operating Weight | 757.5 kg |
| Shipping Weight | 778 kg |
| Shipping Weight | 1715 lb. |
Hitch
| Quick Coupler | Yes |
| Hitch Compatibility | Category 2 |
Chute
| Chute Rotation Degrees | 270 degree (angle) |
| Chute Type | Two-part or three-part |
| Chute Diameter | 32.4 cm |
| Chute Diameter | 12.75 in. |
| Standard Chute Deflector Adjustment | Manual |
| Chute Rotation Type | Hydraulic |
| Optional Chute Deflector Adjustment | Hydraulic cylinder |
Dimensions
| Height | 40 in. |
| Transport Width | 224.8 cm |
| Height | 101.6 cm |
| Transport Width | 88.5 in. |
| Working Width | 88 in. |
| Working Width | 223.5 cm |
| Length | 158.75 cm |
| Length | 62.5 in. |
Setup Time
| Set-Up Time Labor Hours | 1.5 hours |
Tractor Compatibility
| PTO Overload Protection | Shearbolt |
| PTO Speed | Standard: 540 rpm; Optional: 1000 rpm rpm |
| Minimum Power | 33.6 kW |
| Minimum Power | 45 hp |
| Maximum Power | 70.8 kW |
| Maximum Power | 95 hp |
Housing
| Side Panel Thickness | 1.59 cm |
| Side Panel Thickness | 0.63 in. |
| Impeller Housing Thickness | 0.64 cm |
| Impeller Housing Thickness | 0.25 in. |
Skid Shoes
| Skid Shoe Type | Steel, adjustable |
| Skid Shoe Material | Steel |
Chain
| Chain Roller | 80 |
| Chain Idler Adjustment | Automatic |
Impeller
| Optional Secondary Auger Diameter | 14 in. |
| Optional Secondary Auger Diameter | 35.6 cm |
| Impeller Width | 12 in. |
| Impeller Blades | Four |
| Impeller Width | 30.48 cm |
| Impeller Diameter | 28 in. |
| Impeller Diameter | 71.2 cm |
| Impeller Speed | 540 rpm |
Cutting Edge
| Cutting Edge Type | Bolt on reversible |
Drum
