Features
Cutting Edge is Durable for Lasting Performance
Cost savings are realized because of the cutting edge's long-lasting performance.
Blow Snow Anywhere with the Hydraulic Chute Rotation
The hydraulic chute rotation adds versatility by allowing operators to blow snow exactly where they want.
Adjustable Skid Shoes Extend Life of Cutting Edge
The adjustable skid shoes extend the life of the cutting edge.
Impeller
| Impeller Width | 10.5 in. |
| Impeller Blades | Four |
| Impeller Width | 26.7 cm |
| Impeller Diameter | 26 in. |
| Impeller Diameter | 66 cm |
| Impeller Speed | 540 rpm |
Warranty period
| Gear Box Warranty Period | 1 year |
| Machine Warranty Period | 1 year |
Auger
| Auger Diameter | 50.8 cm |
| Auger Diameter | 20 in. |
| Auger Speed | 170 rpm |
| Auger Overload Protection | Single |
Weights
| Operating Weight | 835 lb. |
| Operating Weight | 378.7 kg |
| Shipping Weight | 447.7 kg |
| Shipping Weight | 987 lb. |
Chute
| Chute Rotation Degrees | 210 degree (angle) |
| Chute Type | Three-part |
| Chute Diameter | 26.7 cm |
| Chute Diameter | 10.5 in. |
| Standard Chute Deflector Adjustment | Hydraulic |
| Chute Rotation Type | Hydraulic |
Dimensions
| Height | 30 in. |
| Height | 76.2 cm |
| Transport Width | 189.2 cm |
| Transport Width | 74.5 in. |
| Working Width | 188 cm |
| Working Width | 74 in. |
| Length | 124.5 cm |
| Length | 49 in. |
Tractor Compatibility
| PTO Overload Protection | Shearbolt |
| PTO Speed | 540 rpm rpm |
| Minimum Power | 30 hp |
| Minimum Power | 22.4 kW |
| Maximum Power | 60 kW |
| Maximum Power | 80 hp |
Hitch
| Quick Coupler | Yes |
| iMatch Compatibility | Yes |
| Hitch Compatibility | Category 1, Category 2 |
Setup Time
| Set-Up Time Labor Hours | 1 hour |
Chain
| Chain Roller | 60 |
| Chain Idler Adjustment | Automatic |
Cutting Edge
| Cutting Edge Type | Replaceable |
Skid Shoes
| Skid Shoe Type | Steel, adjustable |
