Features
Chute Rotation Can Be Easily Adjusted for Versatility
Chute rotation adds versatility by allowing operators to blow snow exactly where they want it. Standard-equipped manual chute rotation adjustments are easily done from the seat of the tractor.
Multiple Hitch Capabilities for Different Uses
SB11 Series Snowblowers have different hitch capabilities. Models SB1148, SB1154, SB1164, and SB1174 are Category 1 and iMatch compatible. Model SB1184 is Category 1 and iMatch compatible and Category 2 and Quik-Coupler compatible. Model SB1194 is Category 2 and Quik-Coupler compatible.
Impeller Blade Provides Fast Snow Removal
Moving snow faster and blowing it farther is simple with four impeller blades on the SB11 Series Snowblowers.
Impeller
| Impeller Width | 10.5 in. |
| Impeller Blades | Four |
| Impeller Width | 26.7 cm |
| Impeller Diameter | 27.5 in. |
| Impeller Diameter | 69.9 cm |
| Impeller Speed | 540 rpm |
Warranty period
| Gear Box Warranty Period | One year |
| Machine Warranty Period | 1 year |
Auger
| Auger Diameter | 50.8 cm |
| Auger Diameter | 20 in. |
| Auger Speed | 170 rpm |
| Auger Overload Protection | Single |
Weights
| Operating Weight | 1021 lb. |
| Operating Weight | 463.1 kg |
| Shipping Weight | 536.1 kg |
| Shipping Weight | 1182 lb. |
Chute
| Chute Rotation Degrees | 210 degree (angle) |
| Chute Type | Two-part |
| Chute Diameter | 30.5 cm |
| Chute Diameter | 12 in. |
| Standard Chute Deflector Adjustment | Manual |
| Chute Rotation Type | Manual or hydraulic |
| Optional Chute Deflector Adjustment | Hydraulic cylinder or electric actuator |
Dimensions
| Height | 34 in. |
| Height | 86.4 cm |
| Transport Width | 240 cm |
| Transport Width | 94.5 in. |
| Working Width | 238.8 cm |
| Working Width | 94 in. |
| Length | 140.7 cm |
| Length | 55.38 in. |
Tractor Compatibility
| PTO Overload Protection | Shearbolt |
| PTO Speed | 540 rpm |
| Minimum Power | 35 hp |
| Minimum Power | 26.1 kW |
| Maximum Power | 67.1 kW |
| Maximum Power | 90 hp |
Hitch
| Quick Coupler | Yes |
| Hitch Compatibility | Category 2 |
Setup Time
| Set-Up Time Labor Hours | 1 hour |
Chain
| Chain Roller | 60 |
| Chain Idler Adjustment | Manual |
Cutting Edge
Skid Shoes
| Skid Shoe Type | Steel, adjustable |
