Features
Adjustable Skid Shoes Extend the Life of the Snowblower
Adjustable and replaceable steel skid shoes are in base equipment on the SB11P. Adjustable steel skid shoes can help prevent damage or injury from stones being thrown, by raising the cutting edge off the ground. Replaceable skid shoes will help extend the life of the snowblower.
iMatch™ Quick-Hitch Compatible
The snow blower is compatible with the iMatch™ quick-hitch system and Category 1 hitches.
Blow Snow with Manual or Hydraulic Chute Rotation
All SB11P Series Snowblowers are equipped with manual or hydraulic chute rotation. Chute rotation adds versatility by allowing the operator to blow snow exactly where they want it to go, without repositioning the tractor.
Auger
| Auger - Single / Dual | Single |
| Auger Diameter | 3.175 cm |
| Auger Diameter | 1.25 in. |
| Auger Shaft Diameter | 1.25 in., 3.175 cm |
| Auger Speed | 170 rpm |
| Auger Driven System | Chain No.60 |
| Main Auger Diameter | 15 in., 3.175 cm |
| Auger Overload Protection | Single |
| Second Auger Driven System | N/A |
| Second Auger Diameter | N/A |
Weights
| Operating Weight, Incl. Chute | 610 lb. |
| Operating Weight, Incl. Chute | 276.7 kg |
| Shipping Weight | 290.3 kg |
| Shipping Weight | 640 lb. |
Chute
| Flow Restrictor (Rotation) | Yes |
| Hoses Support | Yes |
| Chute Rotation Degrees | 245 degree (angle) |
| Flow Restrictor (Deflector) | No (available via parts) |
| Chute Position | Right |
| Deflector Adjustment (2 Part Chute) | Manual (hydraulic or electric in option) |
| Chute Rotation Type | Manual or hydraulic |
Drive
| Number Of Auger Shearbolt | 1 (on the driving shaft) |
| Number Of Impeller Shearbolt | 1 (on the driveline) |
| Drive Chain Idler | Yes |
Setup Time
| Set-Up Time Labor Hours | 1 hour |
Tractor Compatibility
| PTO Power Minimum | 15 kW |
| PTO Speed | 540 rpm |
| PTO Power Maximum | 37.3 kW |
| PTO Power Maximum | 50 hp |
| Minimum Power | 15 kW |
| Minimum Power | 20 hp |
| PTO Power Minimum | 20 hp |
| Maximum Power | 37.3 kW |
| Maximum Power | 50 hp |
Dimensions
| Overall Length | 40.25 in. |
| Overall Length | 102.2 cm |
| Overall Height (Without Chute) | 92.7 cm |
| Overall Height (Without Chute) | 36.5 in. |
| Working Height | 25.5 in. |
| Working Height | 64.8 cm |
| Overall Width | 65 in. |
| Overall Width | 165.1 cm |
| Overall Height (With Chute Closed) | 60.5 in. |
| Overall Height (With Chute Closed) | 153.7 cm |
Impeller
| Impeller Shaft Diameter | 1.375 in. |
| Impeller Shaft Diameter | 3.5 cm |
| Impeller Width | 7 in. |
| Impeller Blades | Four |
| Impeller Width | 17.8 cm |
| Direction Of Impeller Rotation | Counterclockwise |
| Impeller Speed | 540 rpm |
Hitch
| Type Of Hitch | 3 point, Category 1 |
| Compatibility With Quick Hitch | Yes |
| Parking Stand | Yes |
Skid Shoes
| Adjustable And Replaceable Skid Shoe | Yes, 3 positions |
| Skid Shoe Material | Carbon steel |
Cutting Edge
| Cutting Edge Material | Carbon steel |
| Cutting Edge Dimension | 0.375 in. x 2 in. in. |
| Cutting Edge Dimension | 0.9525 cm x 5.08 cm cm |
| Replaceable & Reversible Cutting Edge | Fixed |
Warranty period
| Machine Warranty Period | 1 year |
