Features
Increase Efficiency Using Hardened and Tempered C-Shaped Tines
The hardened and tempered C-shaped rotor tines require less horsepower to operate. They are designed to engage the soil at different times for more efficiency.
Prevent Damage With a Cold-Formed Transmission Cover
The sealed cover ensures the protection of the transmission components, preventing transmission damage due to moisture and mud.
Less Maintenance With Gear Drive Transmission
The hardened and tempered gear drive transmission requires less maintenance than a roller chain drive. Enclosed in an oil bath, gear drive components feature higher wear life, decreasing maintenance costs.
Safety And Markings
| Markings | Standard |
| Rear Door Support | Chain |
| Parking Stand | Standard |
Depth Control
| Skid Shoes | Four settings - 2.5 to 9.1 cm, 1 to 3.6 in. |
| Maximum Working Depth | 21.6 cm |
| Maximum Working Depth | 8.5 in. |
| Depth Control Type | Skid shoes |
Dimensions
| Working Width | 2057 mm |
| Working Width | 81 in. |
Tractor Compatibility
| PTO Speed | 540 rpm |
| Minimum Power | 40 hp |
| Minimum Power | 29.8 kW |
| Maximum Power | 44.7 kW |
| Maximum Power | 60 hp |
Rotor
| Blades (Quantity) | 6 |
| Flanges (Quantity) | 10 |
| Rotor Rotation | Forward |
Gearbox
Weight
| Weight Without Drive Shaft | 827 lb. |
| Weight Without Drive Shaft | 375 kg |
Drive System
| Drive System Type | Gear |
| Side Drive | Gear |
PTO Shaft
| Clutch Type | Friction |
| PTO Shaft Type | Category 4 with slip clutch |
Hitch
| iMatch™ Compatible (Category 1) | Yes |
| 3-Point Compatible | Category 1 & 2 |
Blade
Setup Time
Warranty
| Time Period | 1-year whole goods/3-year gearbox |
Duty
