Features
Prevent Damage With a Cold-Formed Transmission Cover
The sealed cover ensures the protection of the transmission components, preventing transmission damage due to moisture and mud.
Improve Performance With Reverse Tilling Option
Reverse tilling easily breaks up compacted and rocky soils as well as sod and hard clay. Reverse tines rotation keep the tiller in the ground and prevent the implement from walking on top of the hard soil.
Less Maintenance With Gear Drive Transmission
The hardened and tempered gear drive transmission requires less maintenance than a roller chain drive. Enclosed in an oil bath, gear drive components feature higher wear life, decreasing maintenance costs.
Safety And Markings
| Markings | Standard |
| Rear Door Support | Chain |
| Parking Stand | Standard |
Depth Control
| Skid Shoes | Four settings - 0 to 7.1 cm; 0 to 2.8 in. |
| Maximum Working Depth | 19 cm |
| Maximum Working Depth | 7.5 in. |
| Depth Control Type | Skid shoes |
Dimensions
| Working Width | 1402 mm |
| Working Width | 55.2 in. |
Tractor Compatibility
| PTO Speed | 540 rpm |
| Minimum Power | 18 hp |
| Minimum Power | 13.4 kW |
| Maximum Power | 26.1 kW |
| Maximum Power | 35 hp |
Rotor
| Blades (Quantity) | 6 |
| Flanges (Quantity) | 6 |
| Rotor Rotation | Reverse |
Gearbox
Weight
| Weight Without Drive Shaft | 545 lb. |
| Weight Without Drive Shaft | 247.2 kg |
Drive System
| Drive System Type | Gear |
| Side Drive | Gear |
PTO Shaft
| Clutch Type | Friction |
| PTO Shaft Type | Category 3 with slip clutch |
Hitch
| iMatch™ Compatible (Category 1) | Yes |
| 3-Point Compatible | Limited Category 1 |
Blade
Setup Time
Warranty
| Time Period | 1-year whole goods/3-year gearbox |
Duty
