Features
Less Maintenance With Gear Drive Transmission
The hardened and tempered gear drive transmission requires less maintenance than a roller chain drive. Enclosed in an oil bath, gear drive components feature higher wear life, decreasing maintenance costs.
Increase Efficiency Using Hardened and Tempered C-Shaped Tines
The hardened and tempered C-shaped rotor tines require less horsepower to operate. They are designed to engage the soil at different times for more efficiency.
Prevent Damage With a Cold-Formed Transmission Cover
The sealed cover ensures the protection of the transmission components, preventing transmission damage due to moisture and mud.
Safety And Markings
| Markings | Standard |
| Rear Door Support | Chain |
| Parking Stand | Standard |
Depth Control
| Skid Shoes | Four settings - 0 to 7.1 cm; 0 to 2.8 in. |
| Maximum Working Depth | 19 cm |
| Maximum Working Depth | 7.5 in. |
| Depth Control Type | Skid shoes |
Dimensions
| Working Width | 1402 mm |
| Working Width | 55.2 in. |
Tractor Compatibility
| PTO Speed | 540 rpm |
| Minimum Power | 18 hp |
| Minimum Power | 13.4 kW |
| Maximum Power | 26.1 kW |
| Maximum Power | 35 hp |
Rotor
| Blades (Quantity) | 6 |
| Flanges (Quantity) | 6 |
| Rotor Rotation | Forward |
Gearbox
Weight
| Weight Without Drive Shaft | 529 lb. |
| Weight Without Drive Shaft | 240 kg |
Drive System
| Drive System Type | Gear |
| Side Drive | Gear |
PTO Shaft
| Clutch Type | Friction |
| PTO Shaft Type | Category 3 with slip clutch |
Hitch
| iMatch™ Compatible (Category 1) | Yes |
| 3-Point Compatible | Limited Category 1 |
Blade
Setup Time
Warranty
| Time Period | 1-year whole goods/3-year gearbox |
Duty
