Features
Helical Rotor for Efficiency
The helical-shaped rotor on the RT Series Rotary Tillers decreases horsepower required to drive units. They are designed so they enter the field at different times for more efficiency.
Skid Shoes Control Depth
The working depth can be adjusted by the height of the skids, which is easily done with the adjustment bracket on the RT Series Rotary Tillers.
Adjustable Offsets Allow Central or Side Position
Adjustable offset allows the tiller to be used in a central or side position with respect to the tractor’s wheel track allowing you to till closer to existing plants and into deep corners. The chain-supported tailgate is self-leveling.
Safety And Markings
| Markings | Standard |
| Rear Door Support | Chain |
| Parking Stand | Standard |
Tractor Compatibility
| PTO Speed | 540 rpm |
| Maximum PTO Power | 75 hp |
| Maximum PTO Power | 56 kW |
| Minimum PTO Power | 26 kW |
| Minimum PTO Power | 35 hp |
Depth Control
| Maximum Working Depth | 22 cm |
| Maximum Working Depth | 8.7 in. |
| Depth Control Type | Skid shoes |
Dimensions
| Outside To Outside Width | 77 in. |
| Outside To Outside Width | 1956 mm |
| Working Width | 1854 mm |
| Working Width | 73 in. |
Weight
| Operating With Skid Shoes | 968 lb. |
| Operating With Skid Shoes | 439 kg |
Gearbox
Hitch
| Quick Coupler (Category 2) | Yes |
| 3-Point Compatible | Category 2 |
Blade
Rotor
| Blades (Quantity) | 6 |
| Flanges (Quantity) | 8 |
Setup Time
Drive System
Warranty
PTO Shaft
Duty
