Features
Hitch Attaches Quickly and Efficiently
The Frontier™ RB20 and RB21 Series Rear Blades are all iMatch™ quick-hitch compatible and compatible with Category 1 hitches. Both systems provide a quick, efficient hookup.
Frame's Tubular Steel Is Crafted for Tough Jobs
The tough, tubular steel frame on Frontier™ RB Series Rear Blades is perfect for grading and its full-radius moldboard more than handles landscaping needs.
Angle Adjustment for Fine Precision Grading and Leveling
The turntable on the RB2060L Series Rear Blades makes it possible to adjust the angle to four different positions in both forward and reverse for those extra-tedious jobs. Manually adjusting the blade forward makes it easy to handle leveling needs in a variety of soil conditions. Swing the blade around and use it to backfill or clear debris or snow.
Weight
| Shipping Per Unit | 426 lb. |
| Shipping Per Unit | 193.2 kg |
| Machine | 177.8 kg |
| Machine | 392 lb. |
Parking Stand
Dimensions
| Moldboard Height | 43.2 cm |
| Moldboard Height | 17 in. |
| Moldboard Length | 60 in. |
| Moldboard Length | 152.4 cm |
| Width In Working Position | 5 ft |
| Width In Working Position | 1.5 m |
| Moldboard Thickness | 0.25 in. |
| Moldboard Thickness | 0.6 cm |
Tractor Requirements
| PTO | 2WD: 48.5; 4WD: 44.7 kW |
| PTO | 2WD: 65; 4WD: 60 hp |
Angle, Tilt, Offset, Pivot
| Tilt Positions/Degrees | Three positions, up to 22 degree (angle) up or down |
| Pivot Angle Degrees | 360 degree (angle) |
| Angle Reverse, Number Of Positions | Three positions, on each side up to 53 degree (angle) |
| Offset Position Left or Right | 6, 12 in. |
| Offset Position Left or Right | 15.2, 30.5 cm |
| Angle Forward, Number Of Positions | Three positions, on each side up to 53 degree (angle) |
Hitch
| Type | Category 1 |
| Quick Hitch Compatibility | iMatch compatible (quick-attach system) |
Duty
Reversible Cutting Edge
| Height | 15.2 cm |
| Height | 6 in. |
| Thickness | 0.5 in. |
| Thickness | 1.3 cm |
Warranty
