Features
Frame's Tubular Steel Is Crafted for Tough Jobs
The tough, tubular steel frame on Frontier™ RB Series Rear Blades is perfect for grading and its full-radius moldboard more than handles landscaping needs.
Longer Wear Life With Reversible Cutting Edge
All Frontier™ RB Series Rear Blade cutting edges are reversible, featuring bevels on both edges to give the blade twice the work life.
Hitch Attaches Quickly and Efficiently
The Frontier™ RB20 and RB21 Series Rear Blades are all iMatch™ quick-hitch compatible and compatible with Category 1 hitches. Both systems provide a quick, efficient hookup.
Weight
| Shipping Per Unit | 350 lb. |
| Shipping Per Unit | 158.8 kg |
| Machine | 138.3 kg |
| Machine | 305 lb. |
Parking Stand
Dimensions
| Moldboard Height | 35.6 cm |
| Moldboard Height | 14 in. |
| Moldboard Length | 84 in. |
| Moldboard Length | 213.4 cm |
| Width In Working Position | 7 ft |
| Width In Working Position | 2.1 m |
| Moldboard Thickness | 0.25 in. |
| Moldboard Thickness | 0.6 cm |
Tractor Requirements
Angle, Tilt, Offset, Pivot
| Tilt Positions/Degrees | 3 |
| Pivot Angle Degrees | 360 degree (angle) |
| Angle Reverse, Number Of Positions | Each side: 0, 15 degree |
| Offset Position Left or Right | 12 in. |
| Offset Position Left or Right | 30.5 cm |
| Angle Forward, Number Of Positions | Each side: 0, 15, 30 degree |
Hitch
| Type | Category 1 |
| Quick Hitch Compatibility | iMatch compatible (quick-attach system) |
Duty
Reversible Cutting Edge
| Height | 15.2 cm |
| Height | 6 in. |
| Thickness | 0.5 in. |
| Thickness | 1.3 cm |
Warranty
