Features
Quick and Efficient Hitch Attachment
The rear blade is compatible with iMatch™ quick-hitch systems, allowing for quick and efficient hookups with Limited Category 1 hitches. This feature enhances the ease of use and speeds up the setup process, making it an optimal choice for efficiency.
Manually Adjustable Angle for Precision
The turntable allows a 360-degree turning radius for optimal leveling. With three forward and three reverse angle positions, the manually adjustable blade angle and offset enable the user to adapt to various soil conditions for precise results.
Heavy Mast Ensures Rigidity
The rear blade features a heavy, welded mast and a 4x4 steel frame, delivering strength and rigidity. This robust construction allows the full-radius moldboard to handle substantial loads, ensuring durability and reliability in demanding tasks.
Weight
| Shipping Per Unit | 201 lb. |
| Shipping Per Unit | 91.2 kg |
| Machine | 70.3 kg |
| Machine | 155 lb. |
Parking Stand
| Standard With Machine | Standard |
Dimensions
| Moldboard Height | 27.9 cm |
| Moldboard Height | 11 in. |
| Moldboard Length | 60 in. |
| Moldboard Length | 152.4 cm |
| Width In Working Position | 5 ft |
| Width In Working Position | 1.8 m |
| Moldboard Thickness | 0.1875 in. |
| Moldboard Thickness | 0.5 cm |
Tractor Requirements
Angle, Tilt, Offset, Pivot
| Pivot Angle Degrees | 360 degree (angle) |
| Angle Reverse, Number Of Positions | Each side: 0, 15 degree |
| Angle Forward, Number Of Positions | Each side: 0, 15, 30 degree |
Hitch
| Type | Limited Category 1 (aftermarket Category 0 lift pins available) |
| Quick Hitch Compatibility | iMatch |
Duty
Reversible Cutting Edge
| Height | 15.2 cm |
| Height | 6 in. |
| Thickness | 0.5 in. |
| Thickness | 1.3 cm |
