Features
Anti-Burying Plate
The anti-burying plate positions the teeth at a steeper angle, ensuring aggressive soil penetration. This design prevents the auger from screwing itself into the ground, allowing soil to pulverize efficiently.
Auger Positioning Handle
The auger positioning handle allows the operator to easily align the auger into the desired position from the operator’s seat prior to digging. The auger positioning handle is in base equipment on all PHD Series Post-Hole Diggers.
Hook-Up Parking Stand
The removable hook-up parking stand makes mounting and detaching the post hole digger to the tractor a safer, easier, one-person job. While in-between jobs, the parking stand allows the post hole digger to be stored in the upright position.
Auger
| Auger Dimensions | 6x48, 9x48, 12x48, 18x48, 24x48 in. |
| Auger Flighting Type | Semi-Double Flighting (6, 9, 12, 18), Double Flighting (24) |
| Auger Weight | 6x48 in. auger: 14.96; 9x48 in. auger:18.6; 12x48 in. auger: 27.2; 18x48 in. auger: 38.56; 24x48 in. auger: 41.73 kg |
| Auger Weight | 6x48 in. auger: 33; 9x48 in. auger: 41; 12x48 in. auger: 60; 18x48 in. auger: 85; 24x48 in. auger: 92 lb. |
| Model Number | PHD395 |
| Auger Points | Spiral Point or Cast Ductile Iron |
| Cutting Edges | Replaceable Carbide Cutting Edge |
Auger Speed
Weight
| Shipping (2 Per Case) | 490 lb. |
| Shipping (2 Per Case) | 249.5 kg |
| Unit | 104.3 kg |
| Unit | 245 lb. |
Tractor Compatibility
| PTO HP Range | 35-95 hp |
| PTO HP Range | 13.4-37.3 kW |
Dimensions
| Yoke OD | 7.9 cm |
| Yoke OD | 3.1 in. |
| Boom OD | 3.5 in. |
| Boom OD | 8.9 cm |
Gearbox
3-Point Hitch
| Category | Category 1 or Category 2 |
