Features
Customizable Weight Distribution

The adjustable design of the arena drag allows for controlled weight distribution across the implement. By modifying the drag’s configuration, operators can manage how deep the tines penetrate the footing, which is crucial for maintaining a consistent surface. This feature is especially valuable in arenas with varying traffic levels, ensuring appropriate care for all areas.
Adjustable S-Tines for Optimal Grooming

The arena drag features adjustable S-tines that effectively break down hard dirt clumps. This adjustability allows users to customize the drag's performance based on specific arena conditions, whether dealing with hard-packed surfaces or softer footing. Tailoring the implement to the arena’s needs ensures a consistently safe and effective surface.
Compatibility with Various Tractors

Designed with quick-hitch compatibility for both medium and large tractors, this arena drag easily integrates into existing equipment lineups. This versatility allows equine businesses to maximize the utility of their current machinery without needing additional investments. Operators can switch between tasks seamlessly, enhancing overall productivity and efficiency.
Construction
| Hitch/S-Tine Tubing | 2 x 2 x 0.1875 in. |
| Hitch/S-Tine Tubing | 5.1 x 5.1 x 0.5 cm |
| Outside Tubing | 2.5 x 2.5 x 0.1875 in. |
| Outside Tubing | 6.4 x 6.4 x 0.5 cm |
| Number of S-Tines | 13 |
| S-Tine Spacing | 3.4 in. |
| S-Tine Spacing | 8.6 cm |
Dimensions
| Working Width | 67.25 in. |
| Working Width | 170.8 cm |
| Overall Width | 74.25 in. |
| Overall Width | 188.6 cm |
| Overall Height | 36.25 in. |
| Overall Height | 92.1 cm |
| Overall Length | 67.75 in. |
| Overall Length | 172.1 cm |
| Height to Hitch Pins | 16.75 in. |
| Height to Hitch Pins | 42.5 cm |
Weight
| Operating Weight | 480 lb. |
| Operating Weight | 217.7 kg |
| Implement Code | 32.16 |
| COG | 30 |
Hitch
| Style | Clevis with pin |
| Category | Cat 1 |
| iMatch/Quick Hitch Compatible | Yes |
Tractor Requirements
| Engine hp | 35-50 hp |
| Engine hp | 26.1-37.3 kW |
