Features
Heavy-Duty Paddle Beater Assemblies
The heavy-duty paddle beater assemblies on the MS11 Series Small Manure Spreaders ensure aggressive shredding action, while the large-diameter beaters deliver greater tip speed for wide, even, and chunk-free spread patterns.
Poly-Bonded Floor
All models come with a poly-bonded floor to reduce apron drag.
Years of Trouble-Free Service
The manure spreaders sides are constructed of durable powder-coated steel.
Paddles
| Horizontal | 10 |
| Replaceable | No |
Dimensions
| Inside Depth | 17 in. |
| Inside Length | 2.23 m |
| Overall Length | 4.17 cm |
| Overall Loading Height - Top Of Flare | 37 in. |
| Inside Width | 122 cm |
| Horizontal Beater Configuration | 4.17 m |
| Top Of Flare Width | 122 cm |
| Overall Width With Standard Tires | 76 in. |
| Overall Width With Standard Tires | 193 cm |
| Inside Depth | 43 cm |
| Overall Length | 13.8 in. |
| Inside Length | 88.8 in. |
| Overall Loading Height - Top Of Flare | 94 cm |
| Inside Width | 48 in. |
| Horizontal Beater Configuration | 13.8 ft |
| Top Of Flare Width | 48 in. |
Beaters
| Lower | Yes |
| Lower | 18.5 in. |
| Lower | 47 cm |
Capacity
| Struck Level | 1.501 m³ |
| Struck Level | 53 cu ft |
| Heaped | 80 bu |
| Heaped | 2.819 m³ |
Weight
| Implement With Base Tire | 517 kg |
| Implement With Base Tire | 1140 lb. |
| Towing Unit Minimum Weight | 2851 lb. |
| Towing Unit Minimum Weight | 1293 kg |
Rear pan
Drive System
| Chain Type | 67H |
| PTO Drive | Yes |
Wheels And Tires
| Spindle Size | 5 cm |
| Spindle Size | 2 in. |
| Hub Style | Greaseable |
| Tire Size | 6.7x15 |
| Axle | Single |
Setup Time
Warranty
Construction
| Box | Corrosion resistant galvanized steel |
| Floor | Bonded poly |
PTO drive
Lighting, Marking, And Safety
