Features
Heavy-Duty Paddle Beater Assemblies
The heavy-duty paddle beater assemblies on the MS11 Series Small Manure Spreaders ensure aggressive shredding action, while the large-diameter beaters deliver greater tip speed for wide, even, and chunk-free spread patterns.
Poly-Bonded Floor
All models come with a poly-bonded floor to reduce apron drag.
Years of Trouble-Free Service
The manure spreaders sides are constructed of durable powder-coated steel.
Paddles
Dimensions
| Inside Depth | 17.5 in. |
| Inside Length | 2.64 m |
| Overall Loading Height - Top Of Flare | 32.5 in. |
| Inside Width | 91 cm |
| Horizontal Beater Configuration | 4.06 m |
| Top Of Flare Width | 91 cm |
| Overall Width With Standard Tires | 58 in. |
| Overall Width With Standard Tires | 147 cm |
| Inside Depth | 44 cm |
| Inside Length | 103.9 in. |
| Overall Loading Height - Top Of Flare | 82 cm |
| Inside Width | 36 in. |
| Horizontal Beater Configuration | 13.4 ft |
| Top Of Flare Width | 36 in. |
Drive System
| Ground Drive | Yes |
| Chain Type | 62 |
Beaters
| Lower | Yes |
| Lower | 17.5 in. |
| Lower | 44 cm |
Capacity
| Struck Level | 0.991 m³ |
| Struck Level | 35 cu ft |
| Heaped | 50 bu |
| Heaped | 1.762 m³ |
Weight
| Implement With Base Tire | 358 kg |
| Implement With Base Tire | 790 lb. |
| Towing Unit Minimum Weight | 2177 lb. |
| Towing Unit Minimum Weight | 987 kg |
Rear pan
Wheels And Tires
| Spindle Size | 4 cm |
| Spindle Size | 1.75 in. |
| Hub Style | Greaseable |
| Tire Size | 7.6x15 |
| Axle | Single |
Setup Time
Warranty
Construction
| Box | Corrosion resistant galvanized steel |
| Floor | Bonded poly |
Lighting, Marking, And Safety
