Features
Heavy-Duty Paddle Beater Assemblies
The heavy-duty paddle beater assemblies on the MS11 Series Small Manure Spreaders ensure aggressive shredding action, while the large-diameter beaters deliver greater tip speed for wide, even, and chunk-free spread patterns.
Poly-Bonded Floor
All models come with a poly-bonded floor to reduce apron drag.
Years of Trouble-Free Service
The manure spreaders sides are constructed of durable powder-coated steel.
Paddles
Dimensions
| Inside Depth | 17 in. |
| Inside Length | 1.83 m |
| Overall Loading Height - Top Of Flare | 30 in. |
| Inside Width | 56 cm |
| Horizontal Beater Configuration | 2.77 m |
| Top Of Flare Width | 73 cm |
| Overall Width With Standard Tires | 42 in. |
| Overall Width With Standard Tires | 107 cm |
| Inside Depth | 43 cm |
| Inside Length | 72 in. |
| Overall Loading Height - Top Of Flare | 76 cm |
| Inside Width | 22 in. |
| Horizontal Beater Configuration | 9.1 ft |
| Top Of Flare Width | 28.5 in. |
Drive System
| Ground Drive | Yes |
| Chain Type | 55 |
Beaters
| Lower | Yes |
| Lower | 20 in. |
| Lower | 51 cm |
Capacity
| Struck Level | 0.38 m³ |
| Struck Level | 13.6 cu ft |
| Heaped | 25 bu |
| Heaped | 0.881 m³ |
Weight
| Implement With Base Tire | 159 kg |
| Implement With Base Tire | 350 lb. |
| Towing Unit Minimum Weight | 961 lb. |
| Towing Unit Minimum Weight | 436 kg |
Rear pan
Wheels And Tires
| Spindle Size | 3 cm |
| Spindle Size | 1.25 in. |
| Hub Style | Greaseable |
| Tire Size | 5x12 |
| Axle | Single |
Setup Time
Warranty
Construction
| Box | Corrosion resistant galvanized steel |
| Floor | Bonded poly |
