Features
iMatch™ Quick-Hitch Compatible for Easy Hookup
Implement-to-tractor hookup is simple with iMatch™ Quick-Hitch Category 1 compatibility.
Reach Stubborn Weeds
For hard-to-reach or small areas, a 100-ft (30.5-m) hose reel kit is available (pictured). All models in the LS20 Series Sprayers include a hand-held spray gun with a 30-ft (9.14-m) hose as standard equipment.
Tank Components for Consistent Placement of Chemicals
Jet agitation or recirculation ensures even mixture of material from start to finish. With an in-line filter and shutoff valve, a dirty filter can be cleaned whenever needed, even if the tank is full. When you’re done, a tank sump allows for complete drainage.
Boom
| Sizes | 12.5, 18, 24 ft, Boomless: 24 ft; 3.8, 5.5, Boomless: 7.3 m |
| Structure | Square tube construction, three sections |
| Fold | Manual |
| Breakaway | Rear |
Application
| Nozzle Type | Nozzle body: 1/4 turn diaphragm with check valve |
| Nozzle Tip | Quantity: 3 (boomless), 5, 7; Type: Air induction, 110-degree flat spray (Boomless: flood) |
| Nozzle Tip Size | 1.5 L/min, 0.4 gpm; Boomless: 1.9 L/min, 0.5 gpm |
| Nozzle Spacing | 76 cm, 30 in.; Boomless: N/A |
| Spot Sprayer | Spray gun, 30 ft (9.1 m) hose |
Dimensions
| Working Width | 12.5, 18 ft |
| Working Width | 3.8, 5.5 m |
| Working Width - Boomless | 24 ft |
| Working Width - Boomless | 7.3 m |
| Transport Width | 4.25, 6.4; Boomless: 2.9 ft |
| Transport Width | 1.32, 1.96; Boomless: 0.89 m |
| Length | 43, 45; Boomless: 39 in. |
| Length | 109, 114; Boomless: 99 cm |
| Height | 40; Boomless: 40 in. |
| Height | 102; Boomless: 102 cm |
Weight
| Dry Weight | 109-230 lb. |
| Dry Weight | 49-104 kg |
| Laden Weight | 651-793 lb. |
| Laden Weight | 295-335 kg |
Control System
| Pump Control | PTO |
| Pressure Control | Adjustable |
| Max Working Pressure | 150 psi |
| Max Working Pressure | 10.3 bar |
| Section Control | 6B control valves (boomless inline valves) |
| Agitation | Jet agitation |
Tank
| Sprayer Tank Capacity | 60 gal. |
| Sprayer Tank Capacity | 227 L |
Pump
| Type | Dry boom |
| PTO | Standard 6-roller pump: Hypro 6 roller PTO cast iron (6500C); Optional 6-roller pump: Hypro 6 roller PTO silver cast (6500XL) |
| Flow Rate | Hypro 6-roller pump maximum flow at 540 rpm: 36.7 L/min, 9.7 gpm |
| Max Pressure | 20.7 bar, 300 psi (6-roller pump) |
| Hose Size | 0.5 in., 1.3 cm |
Hitch
| Type | Category 1; Quick hitch compatible |
Options
| Equipment | Optional hose reel, 100 ft (30.5 m) hose |
