Features
iMatch™ Quick-Hitch Compatible for Easy Hookup
Implement-to-tractor hookup is simple with iMatch™ Quick-Hitch Category 1 compatibility.
Reach Stubborn Weeds
For hard-to-reach or small areas, a 100-ft (30.5-m) hose reel kit is available (pictured). All models in the LS20 Series Sprayers include a hand-held spray gun with a 30-ft (9.14-m) hose as standard equipment.
Tank Components for Consistent Placement of Chemicals
Jet agitation or recirculation ensures even mixture of material from start to finish. With an in-line filter and shutoff valve, a dirty filter can be cleaned whenever needed, even if the tank is full. When you’re done, a tank sump allows for complete drainage.
Boom
| Sizes | 3 m, 3.8 m; 10 ft, 12.5 ft; Boomless: 7.3 m, 24 ft |
| Structure | Square tube construction, three sections |
| Fold | Manual |
| Breakaway | Rear |
Application
| Nozzle Type | Nozzle body: 1/4 turn diaphragm with check valve |
| Nozzle Tip | Quantity: three (boomless), four, five; Type: Air induction, 110-degree flat spray (boomless: flood) |
| Nozzle Tip Size | 0.4 gpm, 1.5 L/min; Boomless: 0.5 gpm, 1.9 L/min |
| Nozzle Spacing | 76 cm, 30 in.; Boomless: N/A |
| Spot Sprayer | Sprayer wand, spray gun; Hose length: 6.1 m, 20 ft |
Dimensions
| Working Width | 10, 12.5 ft |
| Working Width | 3, 3.8 m |
| Working Width - Boomless | 24 ft |
| Working Width - Boomless | 7.3 m |
| Transport Width | 3.6, 4.33; Boomless: 2.75 ft |
| Transport Width | 1.12, 1.32; Boomless: 0.84 m |
| Length | 32; Boomless: 28 in. |
| Length | 81.28; Boomless: 71 cm |
| Height | 32, 34; Boomless: 34 in. |
| Height | 81, 86; Boomless: 86 cm |
Weight
| Dry Weight | 79-96 lb. |
| Dry Weight | 36-44 kg |
| Laden Weight | 79-96 lb. |
| Laden Weight | 36-44 kg |
Control System
| Pump Control | Inline switch |
| Pressure Control | Adjustable; Not applicable on 3 m (10 ft) boom |
| Max Working Pressure | 100 psi |
| Max Working Pressure | 6.9 bar |
| Section Control | Inline valves |
| Agitation | Excess flow plumb to tank |
Tank
| Sprayer Tank Capacity | 45 gal. |
| Sprayer Tank Capacity | 170.3 L |
Tractor Compatibility
| Voltage | 12 |
| Current Draw | At 6.9 bar (100 psi): 10 amp, 17.5 amp |
Pump
| Type | Dry boom |
| Electric | Standard: Electric diaphragm, 15.5 L/min, 4.1 gpm; Optional: Electric diaphragm, 8.3 L/min, 2.2 gpm |
| Flow Rate | Electric pump maximum flow: 8.3 L/min, 2.2 gpm; 15.5 L/min, 4.1 gpm |
| Max Pressure | Electric pump: 6.9 bar, 100 psi |
| Hose Size | 0.95 cm, 1.3 cm; 3/8 in., 1/2 in.; Boomless: 1.3 cm, 0.5 in. |
Hitch
| Type | Limited Category 1/Category 1; Quick hitch compatible |
Options
| Equipment | Optional hose reel; Hose length: 30.5 m, 100 ft |
