Features
Cutting Edges
Frontier landplanes also offer reversible and replaceable cutting edges.
Scarifier Shanks in Base
The scarifier shanks can be easily adjusted for depth control, helping to rip up hard ground and aggressively grade.
Adjustable Skid Shoes Extend Cutting Edge Life
Skid shoes increase the life of the cutting edges on the land planes while avoiding damage to the working surface. The skid shoes are adjustable up and down on each side plate to allow for the creation of a crown on a road for water runoff. By replacing the skid shoes when needed, it will extend the life of the land plane.
Cutting Edge
| Cutting Edge Dimensions | 3/8 X 6 |
| Cutting Edge Material | High Carbon Heat Treated Blades |
| Replaceable | Yes |
| Reversible | Yes |
| Number Of Cutting Edges | 2 |
Dimensions
| Overall Height | 35 in. |
| Height To Hitch Pins | 40.6 cm |
| Overall Height | 88.9 cm |
| Height To Hitch Pins | 16 in. |
| Overall Length | 48 in. |
| Overall Length | 121.9 cm |
| Working Width | 152.4 cm |
| Working Width | 60 in. |
| Overall Width | 65 in. |
| Overall Width | 165.1 cm |
Scarifier
| Depth Range | -2, 0, -2, -4 |
| Number Of Scarifiers | 4 |
| Scarifiers Shank | Heat Treated; 4 Positions |
Hitch
| iMatch™ Compatible (Cat. 1) | Yes |
| 3-Point Compatibility | Cat 1 |
| Hitch Type | Clevis with Pin |
| Hitch Category | Cat 1 |
Scarifier Shanks
| Heat Treated | Yes |
| Scarifier Depth Range | 5.08, 0, -5.08, -10.16 cm |
| Scarifier Depth Range | 2, 0, -2, -4 in. |
| Quantity | 4 |
| Adjustable | 4 Position |
Construction
| Side Panel Thickness | 1/4 with Formed Edges |
| Adjustable Blade Depth | 0 to -2.5 via skid shoes |
| Duty | Standard Duty |
| Adjustable Skid Shoe Thickness | 0.38 in., 0.97 cm |
Skid Shoes
| Thickness | 0.375 in. |
| Thickness | 0.95 cm |
Weight
| Shipping | 509 lb. |
| Shipping | 230.9 kg |
| Operating | 484 lb. |
| Operating | 219.5 kg |
Tractor Compatibility
| Required PTO Horsepower | 18.6-37.3 kW |
| Required PTO Horsepower | 25-50 hp |
