Features
Thermal Switch Protects Hydraulic System
A thermal switch protects the hydraulic system when the hydraulic oil reaches 200 °F (93 °C).
Rear Quick Connect Makes Hookups Convenient
Rear quick connect makes for fast and easy connections.
Optional Oil Cooler Unit
The optional oil cooler unit regulates the temperature of the hydraulic fluid for warmer weather implements.
Dimensions
| Unit Height | 52 in. |
| Unit Height | 1321 mm |
| Unit Width With Weights | 1524 mm |
| Unit Length | 762 mm |
| Unit Length | 30 in. |
| Unit Width With Weights | 60 in. |
| Unit Width | 965 mm |
| Unit Width | 38 in. |
Hydraulics
| Relief Valve Setting | 207 bar |
| Pump RPM | 1836 rpm |
| Oil Reservoir | 15 gal. |
| Relief Valve Setting | 3000 psi |
| Oil Reservoir | 56.8 L |
| Oil Cooler | Standard |
| Tank-Mounted Return Filter | Standard, with breather |
| Tank-Mounted Strainer | Standard |
| Hose Diameter | 19 mm |
| Hose Diameter | 0.75 in. |
| Flow At 3000 Psi (207 Bar) | 60.6 L/min |
| Flow At 3000 Psi (207 Bar) | 16 gpm |
Miscellaneous
| Parking Stands | Standard |
| Counter Weight Support | 700, accepts John Deere weights: 42 lb (19.1 kg) and 70 lb (31.8 kg) |
Shipping
Hitch
| Quick Hitch, Category 2 | No |
| Category | Category 1 |
Setup Time
Tractor Requirements
| PTO Horsepower | 25–35 hp |
| PTO Horsepower | 18.6–26.1 kW |
| PTO RPM | 540 rpm |
| Loader (Current John Deere Series) | 300 |
Warranty
| Time Period (Machine) | 1 year |
Weight
| Shipping | 535 lb. |
| Shipping | 1177 kg |
| Operating | 535 lb. |
| Operating | 1177 kg |
