Features
Efficient Discharge Auger
A 14-in. (35.6-cm) discharge auger simplifies the trenching process by efficiently pushing displaced dirt aside. This functionality prevents backfill into fresh trenches and aids in maintaining smooth operations without clogging.
Seamless Attachment
The trencher is designed with a Category 1 hitch to seamlessly attach to compatible tractors, and it fits well within certain PTO horsepower ranges (15-30 hp [11.2-22.4 kW]). This compatibility ensures it can be used with a variety of John Deere tractors to meet different trenching needs.
Durable Chain for Light-Duty Trenching
The DT1136 features a rugged chain that excels in light-duty trenching tasks. It effectively cuts a 6-in. (15.2-cm) wide trench and can dig up to 36 in. (91.4 cm) deep, which ensures reaching beneath the frost line for a variety of applications.
Chain
| Chain Type - Rating | 38000 lb. |
| Chain Type - Rating | 17236.5 kg |
| Chain Width | 15.2 cm |
| Chain Length In Pitches | 64 |
| Chain Width | 6 in. |
| Chain Pitch | 1.65 in. |
| Chain Pitch | 4.2 cm |
| Chain Type | Rated anti back flex |
Dimensions
| Overall Height | 29 in. |
| Overall Height | 73.7 cm |
| Trench Depth With Auger At 65-Degree Angle | 91.4 cm |
| Overall Length | 79 in. |
| Overall Length | 200.7 cm |
| Overall Width | 38 in. |
| Overall Width | 96.5 cm |
| Trench Depth With Auger At 65-Degree Angle | 36 in. |
Tractor Compatibility
| PTO Horsepower | 15-30 hp |
| PTO Horsepower | 11.2-22.4 kW |
Weight
| Operating Weight | 287.1 kg |
| Operating Weight | 633 lb. |
| Shipping Weight | 650 lb. |
| Shipping Weight | 294.8 kg |
PTO
| Speed | 540 rpm |
| Overload Protection | Slip clutch |
Shipping
Spoil Auger
| Spoil Auger Diameter | 14 in. |
| Spoil Auger Diameter | 35.6 cm |
| Spoil Auger Discharge Reach | 53.3 cm |
| Spoil Auger Discharge Reach | 21 in. |
Parking Stands
Hydraulic System
| Type | One double acting cylinder |
Hitch
| Hitch Compatibility | Category 1 |
Duty
