Features
Disk Blades (Notched or Smooth) Available in Two Sizes
Disk blades are available in 26-in. or 28-in. (66-cm or 71-cm) diameters. Disk blades are available in smooth blades, notched blades, or a combination of front notched blades and rear smooth blades to meet a variety of needs.
Clevis Hitch Is Durable for Those Tough Working Conditions
The clevis hitch has a durable design and is designed for ease of use, long life, and tough working conditions.
Adjustable Disk Blade Scrapers Increase Productivity
Adjustable disk blade scrapers keep disk blades clean and performing in wet and sticky soils for increased productivity.
Disks
| Smooth (Front) Smooth (Rear) | Optional |
| Blade Concavity | Standard: high, Optional: low |
| Quantity | 49 |
| Notched (Front) Smooth (Rear) | Optional |
| Spacing | 26.7 cm |
| Spacing | 10.5 in. |
| Notched (Front) Notched (Rear) | Standard |
Dimensions
| Weight Per Disk | 136 kg |
| Weight Per Disk | 300 lb. |
Available blade sizes
| Blade Option Two | 711x7.9 mm |
| Blade Option Two | 28x0.312 in. |
| Blade Option One | 660x7.9 mm |
| Blade Option One | 26x0.312 in. |
Frame
| Tube Size | 6x6x0.375 in., 15.2x15.2x0.95 cm |
| Duty | Medium |
| Type | Single Offset Folding |
| Main Frame Tube | 6x6x0.375 in., 15.2x15.2x0.95 cm |
Tires
| Size | 12.5L x 15 10 ply |
| Type | Implement- Quantity of 4 |
| Wheel Hub Type | 8 Bolt |
Transport
| Wheel Hub Bearings | Dual tapered roller bearings |
| Ground Clearance With Base Blades | 8 in. |
| Ground Clearance With Base Blades | 20.3 cm |
| Transport - Width | 3.8 m |
| Transport - Width | 12.5 ft |
Setup Time
| Labor Hours | 4-6 for two people |
Tractor Requirements
| Recommended Drawbar HP Range | 134.2-164.1 kW |
| Recommended PTO HP Range | 212-259 hp |
| Recommended Drawbar HP Range | 180-220 hp |
| Recommended PTO HP Range | 158-193 kW |
Weight
| Weight Per Disk Blade | 136 kg |
| Weight Per Disk Blade | 300 lb. |
| Net | 14100 lb. |
| Net | 6395 kg |
Disk Gangs
| Rear Angle | 2 Positions degree (angle) |
| Scrapers | Adjustable |
| Bearing Wear Plates | Standard |
| Bearing Type | Oil Bath Tapered Roller |
| Axle Size | 4.1, 5.4 cm |
| Bearing Standards | Welded, Reinforced |
| Axle Size | 1.625, 2.125 in. |
| Axle Material | Round heat treated alloy steel threaded on both ends |
| Front Angle | 2 Positions degree (angle) |
Working Adjustments
| Maximum Penetration | 0.229 m |
| Maximum Penetration | 0.75 ft |
| Approximate Working Width | 20.75 ft |
| Approximate Working Width | 6.3 m |
Lighting and Safety
| Markings | SMV |
| Safety Tow Chain | Yes |
| Lights | Yes |
