Features
Rear Cultipacker Ensures Good Seed-to-Soil Contact
The rear cultipacker compresses and levels the seedbed, ensuring optimal seed-to-soil contact. With options of corrugated reinforced nylon and cast iron, and a torque arm for constant pressure, it enhances seedbed preparation.
Multiple Seedbox Configurations
CS Series seeders offer multiple seedbox configurations, including standard large-grain, native grass, small-seed legume, and fertilizer boxes, supporting diverse seeding needs and even enabling soil aeration and dethatching by disengaging boxes.
Control the Ground Speed with Ground-Driven Spiked Rollers
The CS Series Seeders feature ground-driven spiked rollers allowing accurate ground speed control by turning the rear roller 40% faster. This enables precise seeding in both new and existing grass or pasture beds.
Box Capacity
| Large Seed Box Capacity | 0.2907 m³ |
| Large Seed Box Capacity | 8.25 bu |
| Legume, Small Seed Box Capacity | 0.0747 m³ |
| Legume, Small Seed Box Capacity | 2.12 bu |
| Fertilizer Box Capacity | 0.2907 m³ |
| Fertilizer Box Capacity | 8.25 bu |
| Native Grass Seed Box Capacity | 8.25 bu |
| Native Grass Seed Box Capacity | 0.2907 m³ |
Roller
| Rear Spike Outside Diameter | 50 cm |
| Nylon Rear Cultipacker | Standard |
| Rear Spike Outside Diameter | 19.75 in. |
| Rear Spike (Quantity) | 150 |
| Front Spike (Quantity) | 132 |
| Spike Material | AR-500 steel |
| Front Spike Outside Diameter | 19.75 in. |
| Front Spike Outside Diameter | 50 cm |
| Cast Iron Rear Cultipacker | Optional |
Setup Time
| Setup Time Labor Hour | 1 hr |
Dimensions
| Unit Height | 54 in. |
| Unit Height | 137 cm |
| Unit Length | 193 cm |
| Unit Length | 76 in. |
| Working Width | 213 cm |
| Working Width | 84 in. |
| Overall Width | 98 in. |
| Overall Width | 249 cm |
Tractor Compatibility
| Minimum Power | 50 hp |
| Minimum Power | 37 kW |
Drive ratio
| Spike Roller Drive Ratio | 15:20 |
| Seed Box Drive Ratio | 17:28 |
Weight
| Stainless Steel Fertilizer Box Weight | 104.8 kg |
| Stainless Steel Fertilizer Box Weight | 231 lb. |
| Second Large Seed Box Weight | 231 lb. |
| Native Grass Box Weight | 321 lb. |
| Base Machine Weight | 948 kg |
| Second Large Seed Box Weight | 104.8 kg |
| Native Grass Box Weight | 145.6 kg |
| Base Machine Weight | 2090 lb. |
| Small Seed Box Weight | 86 lb. |
| Small Seed Box Weight | 39 kg |
| Cast Iron Wheels Weight | 111.1 kg |
| Cast Iron Wheels Weight | 245 lb. |
Hitch
| 3-Point Type Hitch | Category 1, Category 2 |
| Quik-Coupler | Category 2 |
Warranty
| Warranty Time Period | 1 year |
