Features
High Air Velocity and Airflow
The blower features an impressive air velocity of up to 141 mph (227 km/h) and a significant airflow of 6061 cfm, which ensures efficient clearing of debris across landscapes, making it ideal for high-demand tasks.
Adjustable Discharge Outlet
With a convenient lever, the discharge outlet is easily adjustable on the debris blower, allowing the operator to direct debris efficiently to either the left or right side, offering enhanced control in various environments.
Wide Range of Tractor Compatibility
The blower is compatible with various tractor series, accommodating both Category 1 and Category 2 hitches. This flexibility allows it to be used with a wide range of John Deere tractors, enhancing its usability across different platforms.
Dimensions
| Machine Width | 50 in. |
| Machine Width | 127 cm |
| Machine Length | 120 cm |
| Machine Length | 47.123 in. |
| Machine Height | 48.75 in. |
| Machine Height | 124 cm |
Shipping
| Shipping Configuration | Wood crate |
| Units Per Crate | 1 |
Tractor Compatibility
| PTO, Power (Minimum) | 18.6 kW |
| PTO, Rpm | 540 rpm |
| PTO, Power (Minimum) | 25 hp |
| Hitch Category | Category 1 and Category 2 |
Fan
| Fan Speed | 1455 rpm |
| Fan Number Of Blades | 12 |
| Fan Air Velocity | 228 km/h, 141 mph; 378 m/min, 12,400 fpm |
| Fan Airflow | 172 cm² |
| Fan Airflow | 6061 cfm |
| Fan Diameter | 29.5 in. |
| Fan Diameter | 75 cm |
| Fan Width | 25 cm |
| Fan Width | 10 in. |
Discharge/Outlet
| Outlet Size | 270x168 mm, 10.625x6.625 in; Squared: 72,900 mm, 70 in |
| Outlet Height Off Ground | 73 mm |
| Outlet Height Off Ground | 2.875 in. |
| Outlet Location | Right and Left |
| Outlet Adjustable | Yes |
Weight
| Operating Weight | 1516 kg |
| Operating Weight | 689 lb. |
| Shipping Weight | 850 lb. |
| Shipping Weight | 1870 kg |
Construction
| Housing Thickness | 10 gauge |
| Housing Thickness | 3.4 mm |
| Housing Thickness | 0.13 in. |
Gauge Wheels
| Gauge Wheels Standard Or Optional | Standard |
| Gauge Wheels Quantity | 3 |
| Gauge Wheels Material, Solid Or Pneumatic | Semi Pneumatic |
| Gauge Wheels Location, Front, Rear | 3 Front and 1 Rear, swivel |
| Gauge Wheels Size | 12x3 in. |
| Gauge Wheels Size | 305x76.2 mm |
Setup Time
| Setup Time Labor Hours | 0.5 hr |
Warranty
| Warranty Time Period, Machine | 1 year |
