Features
Solid Moldboard Provides Extra Durability
A solid moldboard helps in rough conditions, giving the cutting edge extra power to slice through hard, compacted ground.
Replaceable and Reversible Blade for Longevity
Rear replaceable steel cutting edge ensures precise leveling and a fine finish. The rear blade is reversible for longer life.
Quick-Hitch System Attaches Easily
iMatch™ quick-hitch compatibility provides quick, efficient hookup. The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
Dimensions
| Working Width | 96 in. |
| Working Width | 243.84 cm |
| Unit Height | 39 in. |
| Unit Height | 99.1 cm |
| Unit Depth | 32 in. |
| Unit Depth | 81.28 cm |
| Endplate Thickness | 0.5 in. |
| Endplate Thickness | 1.27 cm |
| Moldboard Thickness | 0.25 in. |
| Moldboard Thickness | 0.64 cm |
Shipping
| Shipping Configuration | One per |
Scarifier Shank and Beam
| Shank Type | Three position with holes |
| Point Type | Replaceable, heat treated |
| Point Quantity | Eight |
| Scarifier Tube | 5 x 5 x 0.25 in. |
| Scarifier Tube | 12.7 x 12.7 x 0.64 cm |
Weight
| Operating Weight | 1045 lb. |
| Operating Weight | 474 kg |
| Shipping Weight | 1070 lb. |
| Shipping Weight | 485.34 kg |
Cutting Edge
| Cutting Edge Reversible | Yes |
| Cutting Edge Quantity | Two |
| Cutting Edge Size | 0.375 x 6 in. |
| Cutting Edge Size | 0.95 x 15.24 cm |
Paint
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
Tractor Compatibility
| PTO Power | 120 hp |
| PTO Power | 86.48 kW |
Tailgate
Box
| Box Capacity | 37.85 cu ft |
| Box Capacity | 1.07 m³ |
| Box Design | High Back Box |
Hitch
| Hitch Compatibility | Category 1 & 2 |
| iMatch™ Compatible (Category 1) | Yes |
Mast
Warranty
| Warranty Time Period | One year |
