Features
Replaceable and Adjustable Scarifiers
Replaceable heavy-duty scarifiers have multiple adjustment holes for quick and easy changes to shank penetration level. The scarifiers work great for the purposes of chipping or deep digging.
Quick-Hitch System Attaches Easily
iMatch™ quick-hitch compatibility provides quick, efficient hookup. The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
Replaceable and Reversible Blade for Longevity
Rear replaceable steel cutting edge ensures precise leveling and a fine finish. The rear blade is reversible for longer life.
Dimensions
| Working Width | 96 in. |
| Working Width | 243.8 cm |
| Unit Height | 36 in. |
| Unit Height | 91.4 cm |
| Unit Depth | 32 in. |
| Unit Depth | 81.3 cm |
| Endplate Thickness | 0.5 in. |
| Endplate Thickness | 1.27 cm |
| Moldboard Thickness | 0.25 in. |
| Moldboard Thickness | 0.64 cm |
Shipping
| Shipping Configuration | One per |
Scarifier Shank and Beam
| Shank Type | Four position with holes |
| Point Type | Replaceable, heat treated |
| Point Quantity | Eight |
| Scarifier Tube | 5 x 5 x 0.25 in. |
| Scarifier Tube | 12.7 x 12.7 x 0.64 cm |
Weight
| Operating Weight | 855 lb. |
| Operating Weight | 387.8 kg |
| Shipping Weight | 880 lb. |
| Shipping Weight | 399.2 kg |
Cutting Edge
| Cutting Edge Reversible | Yes |
| Cutting Edge Quantity | Two |
| Cutting Edge Size | 0.375 x 6 in. |
| Cutting Edge Size | 0.95 x 15.24 cm |
Paint
| Paint Color | John Deere Green |
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
Tractor Compatibility
| PTO Power | 120 hp |
| PTO Power | 86.48 kW |
Tailgate
Box
| Box Capacity | 37.85 cu ft |
| Box Capacity | 1.07 m³ |
| Box Design | High back box |
Hitch
| Hitch Compatibility | Category 1 and 2 |
| iMatch™ Compatible (Category 1) | Yes |
Mast
Warranty
| Warranty Time Period | One year |
