Features
Replaceable and Adjustable Ripper Shanks
Replaceable heavy-duty ripper shanks have multiple adjustment holes for quick and easy changes to shank penetration level. The ripper shanks work great for the purposes of chipping or deep digging.
Quick-Hitch System Attaches Easily
iMatch™ quick-hitch compatibility provides quick, efficient hookup. The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
Replaceable and Reversible Blade for Longevity
Rear replaceable steel cutting edge ensures precise leveling and a fine finish. The rear blade is reversible for longer life.
Dimensions
| Endplate Thickness | 1 cm |
| Endplate Thickness | 0.375 in. |
| Unit Depth | 78.7 cm |
| Unit Height | 33.5 in. |
| Unit Depth | 31 in. |
| Unit Height | 85.1 cm |
| Working Width | 182.9 cm |
| Working Width | 72 in. |
| Moldboard Thickness | 0.188 in. |
| Moldboard Thickness | 0.5 cm |
Shipping
| Shipping Configuration | Two per crate |
Scarifier Shank and Beam
| Point Quantity | 6 |
| Beam Reinforcement Bar Size | 1.27x1.27 cm |
| Beam Reinforcement Bar Size | 0.5x0.5 in. |
| Tubular Scarifier Beam Size | 4x4x0.25 in. |
| Tubular Scarifier Beam Size | 10.16x10.16x0.64 cm |
| Shank Type | Four position with holes |
| Point Type | Hardened, crimped |
Weight
| Operating Weight | 215 kg |
| Operating Weight | 474 lb. |
| Shipping Weight | 509 lb. |
| Shipping Weight | 230.9 kg |
Cutting Edge
| Cutting Edge Quantity | 2 |
| Cutting Edge Size | 0.375x6 in. |
| Cutting Edge Size | 0.95x15.24 cm |
| Cutting Edge Reversible | Yes |
Paint
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
Tractor Compatibility
| PTO Power | 14.2-41.8 kW |
| PTO Power | 19-56 hp |
Tailgate
Box
| Box Design | Box |
| Box Capacity | 15.97 cu ft |
| Box Capacity | 0.45 m³ |
Hitch
| Hitch Compatibility | Category 1 |
| iMatch™ Compatible (Category 1) | Yes |
Mast
Warranty
| Warranty Time Period | One year |
