Features
Adjustable and Replaceable Ripper Shanks
Heavy-duty ripper shanks with multiple adjustment holes provide versatility for various ground conditions. They can be easily adjusted for different penetration levels, making them ideal for chipping or deep digging.
iMatch™ Quick-Hitch Compatible for Quick, Efficient Hookup
The iMatch™ Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
Cutting Edge Is Strategically Positioned for a Fine Finish
The BB50L Series Box Blade cutting edge ensures precise leveling and a fine finish. The reversible blade provides twice the wear life.
Dimensions
| Endplate Thickness | 0.8 cm |
| Endplate Thickness | 0.313 in. |
| Unit Depth | 78.7 cm |
| Unit Height | 33 in. |
| Unit Depth | 31 in. |
| Unit Height | 83.8 cm |
| Working Width | 127 cm |
| Working Width | 50 in. |
| Moldboard Thickness | 0.188 in. |
| Moldboard Thickness | 0.48 cm |
Shipping
| Shipping Configuration | Two per crate |
Scarifier Shank and Beam
| Point Quantity | 4 |
| Tubular Scarifier Beam Size | 4x4x0.25 in. |
| Tubular Scarifier Beam Size | 10.16x10.16x0.64 cm |
| Shank Type | Four position with holes |
| Point Type | Hardened, crimped |
Weight
| Operating Weight | 163.3 kg |
| Operating Weight | 360 lb. |
| Shipping Weight | 797 lb. |
| Shipping Weight | 362 kg |
Cutting Edge
| Cutting Edge Quantity | 2 |
| Cutting Edge Size | 0.375x6 in. |
| Cutting Edge Size | 0.95x15.24 cm |
| Cutting Edge Reversible | Yes |
Paint
| Paint Color | John Deere green |
Setup Time
| Set-Up Time Labor Hours | 0.25 hr |
Tractor Compatibility
| PTO Power | 19 kW |
| PTO Power | 26 hp |
Tailgate
Box
| Box Design | Box |
| Box Capacity | 10.65 cu ft |
| Box Capacity | 0.3 m³ |
Hitch
| Hitch Compatibility | Category 1 |
| iMatch™ Compatible (Category 1) | Yes |
Mast
Warranty
| Warranty Time Period | One year |
