Features
Strategically Positioned Cutting Edge
The BB Series Box Blade cutting edge ensures precise leveling and a fine finish. It is also reversible for twice the wear life.
iMatch™ Quick Hitch Compatible for Efficient Hookup
The iMatch™ Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
Floating Tailgate Helps in Rough Conditions
The tailgate floats, allowing material to flow through the blade during heavy grading conditions.
Dimensions
| Endplate Thickness | 1 cm |
| Endplate Thickness | 0.375 in. |
| Unit Depth | 78.7 cm |
| Unit Height | 33.5 in. |
| Unit Depth | 31 in. |
| Unit Height | 85.1 cm |
| Working Width | 182.9 cm |
| Working Width | 72 in. |
| Moldboard Thickness | 0.1875 in. |
| Moldboard Thickness | 0.5 cm |
Shipping
| Shipping Configuration | One unit |
Scarifier Shank and Beam
| Point Quantity | 6 |
| Beam Reinforcement Bar Size | 0.95x2.54 cm |
| Beam Reinforcement Bar Size | 0.375x1 in. |
| Tubular Scarifier Beam Size | 4x4x0.25 in. |
| Tubular Scarifier Beam Size | 10.16x10.16x0.64 cm |
| Shank Type | Three position with holes |
| Point Type | Replaceable |
Weight
| Operating Weight | 265.4 kg |
| Operating Weight | 585 lb. |
| Shipping Weight | 675 lb. |
| Shipping Weight | 306.2 kg |
Cutting Edge
| Cutting Edge Quantity | 2 |
| Cutting Edge Size | 0.5x6 in. |
| Cutting Edge Size | 1.27x15.24 cm |
| Cutting Edge Reversible | Yes |
Paint
Setup Time
| Set-Up Time Labor Hours | 0.5 hr |
Tractor Compatibility
| PTO Power | 52.5 kW |
| PTO Power | 70 hp |
Tailgate
Box
| Box Design | Reinforced with formed edge end plates |
| Box Capacity | 19 cu ft |
| Box Capacity | 0.54 m³ |
Mast
Warranty
| Warranty Time Period | 1 year |
Hitch
| Hitch Compatibility | Category 1 |
