Features
Strong Frame for Added Durability
The AY12 Series Four-in-One Bucket frame is built with welded components and high-tensile, heavy-gauge steel for maximum durability.
Serrated Edge for Secure Movement
The AY12 Series serrated edge firmly grasps material for secure movement.
Attachment is Quick and Easy
Attaching the four-in-one bucket to a John Deere loader is easy with its quick-change and global attaching systems. Just line up the loader's connecting points to the attachment frame and lock in place.
Dimensions
| Height | 50.8 in. |
| Height | 20 cm |
| Cutting Width | 84 in. |
| Cutting Width | 213.4 cm |
| Depth | 74.6 cm |
| Depth | 29.38 in. |
| Width | 213.4 cm |
| Width | 84 in. |
| Clam Opening | 88.3 cm |
| Clam Opening | 34.78 in. |
Weight
| Operational Weight | 460.4 kg |
| Operational Weight | 1015 lb. |
| Shipping Weight | 471.7 kg |
| Shipping Weight | 1040 lb. |
Hydraulic Cylinders
| Hydraulic Cylinders Type | Two double-acting |
Clamp force
| Clamp Force Closed | 13567.1 N |
| Clamp Force Closed | 3050 lb-ft |
| Clamp Force Open | 21413.7 N |
| Clamp Force Open | 4814 lb-ft |
Warranty
| Warranty Time Period | 1 year |
Attachment Carrier
| Current Series Style | Global |
Setup Time
| Set-Up Time Labor Hours | 0.25 hr |
