Features
Strong Frame for Durability
The AY11H 4-In-1 Bucket features a rugged frame crafted with welded components and high-tensile, heavy-gauge steel, ensuring maximum durability and longevity across demanding tasks.
Serrated Edge for Enhanced Grip
The serrated edge of the AY11H Bucket provides enhanced material grip, facilitating secure material handling and preventing slippage during transport and operation.
Easy, Quick Attachment
Designed for compatibility with 300 to 500 Series Loaders, the bucket can be effortlessly attached using its quick-change and global attaching systems, simplifying the setup process.
Dimensions
| Height | 26.94 in. |
| Height | 68.4 cm |
| Cutting Width | 60 in. |
| Cutting Width | 152.4 cm |
| Depth | 71.1 cm |
| Depth | 28.01 in. |
| Width | 157.2 cm |
| Width | 61.88 in. |
| Clam Opening | 72.3 cm |
| Clam Opening | 28.45 in. |
Weight
| Operational Weight | 163.3 kg |
| Operational Weight | 360 lb. |
| Shipping Weight | 174.6 kg |
| Shipping Weight | 385 lb. |
Hydraulic Cylinders
| Hydraulic Cylinders Type | Two double-acting |
Clamp force
| Clamp Force Closed | 10577.9 N |
| Clamp Force Closed | 2378 lb-ft |
| Clamp Force Open | 16035.8 N |
| Clamp Force Open | 3605 lb-ft |
Warranty
| Warranty Time Period | 1 year |
Attachment Carrier
| Current Series Style | 300 and 400 |
Setup Time
| Set-Up Time Labor Hours | 0.25 hr |
