Features
Parking Stand Kit Available
An optional parking stand kit is available for the AV20G Series Root Grapples, providing an efficient solution for storage when the implement is not in use. For safe parking, it is recommended to completely close the grapple clamps and place the unit on a solid, level surface.
Quick and Easy Connection System
Attaching the AV20G Series Root Grapple to a John Deere loader is facilitated by quick-change and global attaching systems. This allows for a simple alignment of the loader's connecting points to the attachment frame and secure locking. The global attaching system is compatible with all John Deere loaders equipped with a global Category 1 attachment carrier.
Replaceable, Weld-On Wear Tips
The root grapple is designed with replaceable wear tips, extending the implement's wear life. This feature simplifies maintenance, ensuring optimal functionality and longevity by allowing worn tips to be easily replaced.
Dimensions
| Height | 25 in. |
| Height | 63.5 cm |
| Grapple Opening | 50 in. |
| Grapple Opening | 127 cm |
| Cutting Width | 77 in. |
| Cutting Width | 195.6 cm |
| Depth | 38.1 cm |
| Depth | 15 in. |
| Width | 195.6 cm |
| Width | 77 in. |
Grapple Clamping Force
| Maximum | 12010.2 N |
| Maximum | 270 lb-ft |
Grapple Tines
| Grapple Tine Spacing | 15 in. |
| Grapple Tine Spacing | 38.1 cm |
| Upper Tines - Quantity | 5 |
| Lower Tines - Quantity | 4 |
Warranty
Weight
| Shipping | 1040 lb. |
| Shipping | 471.7 kg |
| Operational | 970 lb. |
| Operational | 440 kg |
Hydraulic Cylinders
Setup Time
Attachment Type
| Current Series Style | Global |
