Features
Reversible Cutting Edges
The heat-treated steel cutting edge is reversible, doubling durability and work life. This efficiency makes it ideal for long periods of demanding use in various terrains. The reversible nature ensures that both sides can be utilized, minimizing downtime for edge replacements.
Hydraulic Angle Adjustment
The hydraulic angle can be adjusted up to 30 degrees on each side, allowing the operator to tackle challenging spots with ease. This adjustment not only saves time but also ensures professional-grade results in difficult-to-reach places.
Heavy-Duty Frame Construction
The loader-mounted front blade is crafted from heavy-duty steel to resist bending. This construction provides long-term reliability and wear capability, making it perfect for extensive fieldwork and robust applications.
Dimensions
| Width | 108 in. |
| Width | 274.3 cm |
| Height | 32 in. |
| Height | 81.3 cm |
| Depth | 55 in. |
| Depth | 139.7 cm |
| Cutting Width | 108 in. |
| Cutting Width | 274.3 cm |
| Weight, Shipping | 1315 lb. |
| Weight, Shipping | 596.5 kg |
| Weight, Operating | 1265 lb. |
| Weight, Operating | 573.8 kg |
Skid Shoes
Weight
| Operational Weight | 1265 lb. |
| Operational Weight | 573.8 kg |
| Shipping Weight | 1315 lb. |
| Shipping Weight | 596.5 kg |
Hydraulic Cylinders
| Hydraulic Cylinder Type | Two double-acting |
Moldboard
| Moldboard Thickness | 0.13 in. |
| Moldboard Thickness | 3.4 mm |
| Moldboard Thickness | 10 gauge |
| Moldboard Height | 31.8 in. |
| Moldboard Height | 808 mm |
Setup Time
| Setup Time Labor Hours | 0.5 hr |
Warranty
| Warranty Time Period | One year |
Attachment Carrier
| Current Series Style | 600, 700 |
Angle/Pivot
| Angle/Pivot Standard Adjustment | Hydraulic |
| Angle/Pivot Degrees (Each Side) | 30 |
