Features
Heavy-Duty Grapples
The AD11E Series Grapple Buckets are built with heavy-duty steel to maximize strength and resilience. This enhances the bucket's resistance to bending and prolongs its wear lifespan. Its slim design ensures excellent visibility while still being robust enough to grasp large and heavy objects.
Quick and Easy Attachment
Designed for John Deere 300-500 Series Loader attachment carriers, the AD11E's quick-change system allows for easy attachment to a loader. Simply align the loader’s connecting points to the attachment frame and lock it securely in place.
Strong Clamp Force
Equipped with two double-acting hydraulic cylinders, the AD11E provides a strong clamp force of 1,345 lbf (5,982.9 N) when closed. This ensures secure grip on debris for efficient operation, making it ideal for demanding tasks.
Dimensions
| Width | 60 in. |
| Width | 152.4 cm |
| Height | 22 in. |
| Height | 55.9 cm |
| Depth | 32 in. |
| Depth | 81.3 cm |
| Cutting Width | 60 in. |
| Cutting Width | 152.4 cm |
| Clam Opening | 32.75 in. |
| Clam Opening | 83.2 cm |
Weight
| Operational Weight | 540 lb. |
| Operational Weight | 244.9 kg |
| Shipping Weight | 570 lb. |
| Shipping Weight | 258.5 kg |
Hydraulic Cylinders
| Hydraulic Cylinders Type | Two-double-acting |
Clamp force
| Clamp Force Closed | 1122 lb-ft |
| Clamp Force Closed | 4990.9 N |
Warranty
| Warranty Time Period | 1 year |
Attachment Carrier
| Current Series Style | 300 and 400 |
Setup Time
| Set-Up Time Labor Hours | 0.25 hr |
