Features
Hydraulic Lift and Angling
The front blade has a vertical, straight ahead working range of approximately 12 in. (30.5 cm), with enough height for clearance over curbs and the ability to work below ground level. Left- and right-angle capabilities: up to 27 degrees.
Breakaway Feature
The breakaway feature includes two large coil springs that help the blade edge retract when encountering a solid object. This reduces the operational shock experienced by the driver and minimizes the risk of blade damage. A locking pin keeps the blade secured in the desired position.
Heavy-Duty Construction
A reinforcing angle behind the blade's front edge ensures durability. The blade has a replaceable cutting edge that forms a continuous curve, rolling material rather than pushing it, which enhances capacity and extends the blade's life.
Blade Float
Range Of Lift
| Garden Tractors - Above Ground Level | 34.3 cm |
| Garden Tractors - Above Ground Level | 13.5 in. |
| Compact Utility Tractors - Above Ground Level | 34.3 cm |
| Compact Utility Tractors - Above Ground Level | 13.5 in. |
Material Thickness
| Blade | 7 gauge |
| Blade | 4.6 mm |
| Blade | 0.18 in. |
| Replaceable Scraper Edge | 8 mm |
| Replaceable Scraper Edge | 0.315 in. |
Angling Positions
| Right And Left | 27 degree (angle) |
Blade Trip
Cutting Width
| Blade Straight | 152 cm |
| Blade Straight | 60 in. |
| Blade Angled | 147.2 cm |
| Blade Angled | 58 in. |
Weight
| Approximate Weight | 60.8 kg |
| Approximate Weight | 134 lb. |
Blade Skid Shoes
| Type | Eight position / Standard: heavy-duty skid shoes |
