Features
Robust Power Transfer
Equipped with a 2000-rpm front PTO kit, the broom receives efficient power transfer necessary for tackling tough materials. Its design ensures optimal performance, making it suitable for demanding cleaning landscapes.
Hydraulic Angling Capability
The heavy-duty rotary broom features a hydraulic angling cylinder kit, allowing the broom to pivot from 0 to 27 degrees left or right. This feature provides enhanced maneuverability and precision when cleaning large areas.
Polypropylene Wafers
Equipped with 22 convoluted polypropylene wafers, this broom ensures efficient sweeping. The flicking action of the bristles guarantees optimal debris collection, and even wear is achieved by replacing all wafers at once.
Brush
| Diameter | 66 cm |
| Diameter | 26 in. |
| Number Of Wafers | 32 |
| Drive | Front power take-off (PTO) |
Angling Method
| On X700 | Hydraulic |
| On Compact Utility Tractors | Hydraulic (dual selective control valve [SCV] joystick controls angling) |
Drive System
| Brush Drive | Front power take-off (PTO) |
| Final Drive | Three-to-one, spiral bevel gear, synthetic extreme-pressure lubricant, shear pin protected, central location |
Clearing Width
| Broom Angled | 136 cm |
| Broom Angled | 53.5 in. |
Hydraulic Angling Positions
| Right And Left | 27 degree (angle) |
Hood
| Type | Steel three-piece bolt-together |
Broom Head Protection
| Type | Shear bolts (broom comes with four extra bolts) |
