Features
Adjustable Skid Shoes
Adjustable skid shoes offer eight different height settings, enabling operators to choose the appropriate blading height for various tasks. This adjustability simplifies achieving uniform grading and prolongs skid shoes' utility. Optional heavy-duty skid shoes available for purchase.
Breakaway Feature
The breakaway feature includes two large coil springs that help the blade edge retract when encountering a solid object. This reduces the operational shock experienced by the driver and minimizes the risk of blade damage. A locking pin keeps the blade secured in the desired position.
Heavy-Duty Construction
A reinforcing angle behind the blade's front edge ensures durability. The blade has a replaceable cutting edge that forms a continuous curve, rolling material rather than pushing it, which enhances capacity and extends the blade's life.
Blade Float
Range Of Lift
| Garden Tractors - Above Ground Level | 27.9 cm |
| Garden Tractors - Above Ground Level | 11 in. |
| Garden Tractors - Below Ground Level | 9.9 cm |
| Garden Tractors - Below Ground Level | 3.5 in. |
| Compact Utility Tractors - Above Ground Level | 27.9 cm |
| Compact Utility Tractors - Above Ground Level | 11 in. |
| Compact Utility Tractors - Below Ground Level | 3.5 cm |
| Compact Utility Tractors - Below Ground Level | 1.5 in. |
Angling Positions
| Right And Left | 27 degree (angle) |
Blade Trip
Material Thickness
| Blade | 3.05 mm |
| Blade | 0.12 in. |
| Replaceable Scraper Edge | 4.78 mm |
| Replaceable Scraper Edge | 0.188 in. |
Cutting Width
| Blade Straight | 137 cm |
| Blade Straight | 54 in. |
| Blade Angled | 132.6 cm |
| Blade Angled | 52.2 in. |
Weight
| Approximate Weight | 23 kg |
| Approximate Weight | 50 lb. |
Blade Skid Shoes
