Features
Polypropylene Wafers
Equipped with 22 convoluted polypropylene wafers, this broom ensures efficient sweeping. The flicking action of the bristles guarantees optimal debris collection, and even wear is achieved by replacing all wafers at once.
Robust Power Transfer
Equipped with a 2000-rpm front PTO kit, the broom receives efficient power transfer necessary for tackling tough materials. Its design ensures optimal performance, making it suitable for demanding cleaning landscapes.
Hydraulic Angling Capability
The heavy-duty rotary broom features a hydraulic angling cylinder kit, allowing the broom to pivot from 0 to 27 degrees left or right. This feature provides enhanced maneuverability and precision when cleaning large areas.
Brush
| Diameter | 53.3 cm |
| Diameter | 21 in. |
| Material | Polypropylene |
| Number Of Wafers | 22 |
| Drive | Front power take-off (PTO) |
| Sweeping Height | 13 mm |
| Sweeping Height | 5 in. |
| Speed | 220 rpm |
| Top Speed | 369 m/min |
| Top Speed | 1209 fpm |
Drive System
| Input | Telescoping drive shaft |
| Center Drive | Number 50 roller chain from offset 3:1 gearbox |
| Brush Shaft | Oil-filled metal flange bearing and thrust bearing, greaseable |
Caster Wheels
| Size | 159x83 mm |
| Size | 6.25x3.25 in. |
| Adjustment | 13 mm |
| Adjustment | 0.5 in. |
Unitized Structure Material
| Housing | 14 gauge |
| Housing | 1.9 mm |
| Housing | 0.07 in. |
| Frame | 6 mm |
| Frame | 0.25 in. |
| Lateral Float | Hitch clearance |
Weight
| Weight (Broom Only) | 109 kg |
| Weight (Broom Only) | 240 lb. |
| Shipping Weight | 139 kg |
| Shipping Weight | 306 lb. |
Hydraulic Angling Positions
| Right And Left | 27 degree (angle) |
Clearing Width
| Broom Straight | 132 cm |
| Broom Straight | 52 in. |
| Broom Angled | 122 cm |
| Broom Angled | 48 in. |
Storage Stands
| Storage Stands | Standard equipment |
